UNITRONIC® ALARM CABLE
- Unshielded
- product information (PDF)
■ Application range
- Flexible cables normally used for the wiring of burglar and security alarm and other low voltage circuits
- Suitable for interconnection between control unit systems, sensors and alerting devices
- For indoor installation
■ Product features
- Flame retardant in acc. to IEC 60332-1-2
■ Product Make-up
- Stranded bare annealed copper wires
- PVC core insulation
- PVC outer sheath, white
■ Technical data
Core identification code
4 core: RD/BK/WH/BU
6 core: RD/BK/WH/BU/YE/GN
Mutual capacitance
Approx. 120 nF/km, at 800 Hz
Peak operating voltage
50 Vrms (not for power applications)
Minimum bending radius
10 x cable diameter
Test voltage
1500 V
Temperature range
-30°C to +70°C
| Article number | Number of core and mm² per conductor | Outer diameter (mm) | Copper index (kg/km) | Weight (kg/km) |
| 3804934 | 4×0.25 | 4,3 | 9,6 | 28,3 |
| 3804936 | 6×0.25 | 5,1 | 14,2 | 38,8 |
