LAPP KABEL ÖLFLEX® 500 P
Flexible, abrasion-, oil- and cold-resistant workshop cable with PUR outer sheath
ÖLFLEX® 500 P – PUR connection cable with highly flexible conductor design and high mechanical strength for durable and oil-resistant application with hand-held equipment.
- High mechanical strength
- Good oil resistance
- Extra flexible conductor design
Benefits
- Durable under harsh conditions thanks to robust PUR sheath material
- Resistant to contact with many mineral oil-based lubricants, diluted acids, aqueous alkaline solutions and other chemical media
- Wide temperature range for applications in harsh climatic environments
- High flexibility simplifies installation when space is limited and use with electrical hand-held devices
- The signal colour of the outer sheath increases safety and visual perception
Application range
- Portable hand-held electrical devices such as drills, sanders, jig saws or grinders
- Portable electrical devices for the home and garden
- Connection and extension cables
Product features
- Resistant to oil and drilling fluids according to IEC 61892-4, appendix D
- Abrasion-resistant and notch-resistant
- Flexible at temperatures down to -40 °C
- Halogen-free and flame-retardant (IEC 60332-1-2)
- Resistant to hydrolysis and microbes
Norm references / approvals
- Based on VDE 0285
Design
- Extra-fine wire strand made of bare copper
- Core insulation made of TPE compound
- Cores twisted together
- PUR outer sheath
- Sheath colour: Orange
■ Technical data
Classification
- ETIM 5.0 Class-ID: EC001578
- ETIM 5.0 Class-Description: Flexible cable
Core identification code
- Coloured according to VDE 0293-308, see appendix T9
Conductor design
- Extra-fine wire according to VDE 0295, class 6 / IEC 60228 class 6
Minimum bending radius
- Occasional flexing: 10 x outer diameter
- Fixed installation: 4 x outer diameter
Nominal voltage
- U0/U: 300/500 V
Test voltage
- 3000 V
Protective conductor
- G = with GN-YE protective conductor
- X = without protective conductor
Temperature range
- Occasional flexing: -40°C to +80°C
- Fixed installation: -50°C to +80°C
| Article number | Number of cores and mm² per conductor | Outer diameter (mm) | Copper index (kg/km) | Weight (kg/km) |
| ÖLFLEX® 500 P | ||||
| 0012345 | 2 X 1.0 | 7.2 | 19.5 | 64 |
| 0012346 | 3 G 1.0 | 7.6 | 29.0 | 77 |
| 00123473 | 4 G 1.0 | 8.5 | 38.4 | 96 |
| 00123483 | 5 G 1.0 | 9.2 | 48.0 | 120 |
| 0012351 | 2 X 1.5 | 8.0 | 29.0 | 81 |
| 0012352 | 3 G 1.5 | 8.7 | 43.0 | 105.3 |
| 00123543 | 4 G 1.5 | 9.6 | 58.0 | 135 |
| 00123533 | 5 G 1.5 | 10.8 | 72.0 | 158.9 |
| 0012365 | 3 G 2.5 | 10.9 | 72.0 | 173.2 |
| 00123553 | 4 G 2.5 | 11.9 | 96.0 | 204 |
| 00123663 | 5 G 2.5 | 13.2 | 120.0 | 254 |
