New
UNITRONIC® LAN 500 U/FTP CAT.6A

• PVC or LSHF outer sheath

• Solid conductor

• 500 MHz
• product information (PDF)

■ Application range

• Data transfer for horizontal network backbone for wiring office administration and development buildings

• Cable run should not exceed 100 m in acc. to ANSI/TIA-568-C.2, ISO/IEC 11801 and EN 50173


■ Product features

• Transmission rate up to 500 MHz

• Flame retardant acc. to IEC 60332-1-2

• Low smoke acc. to IEC 61034-1 (for LSHF outer sheath only)

• Halogen free acc. to IEC 60754-1 (for LSHF outer sheath only)


■ Product Make-up

• Solid bare conductor

• Foam PE core insulation

• Individual pair screen of Al foil

• Solid tinned copper drain wire

• PVC or LSHF outer sheath

• Colour: pebble grey, RAL 7032

■ Technical data

Core identification code
Pair 1: blue + white/blue
Pair 2: orange + white/orange
Pair 3: green + white/green
Pair 4: brown + white/brown
Mutual capacitance
max. 5.6 nF/100 m
Minimum bending radius
Fixed installation: 4 x cable diameter
Characteristic impedance
(at 100 MHz): 150 ± 15 Ohm
Temperature range
-30°C to +70°C
