1-Port 10/100/1000M Ethernet Media Converter
MC201
MC201, 10/100/1000Mbps adaptive Gigabit Ethernet fiber converter uses the switching technology to conduct media conversion, which meets the standards of IEEE802.3, IEEE802.3u, IEEE802.3z and IEEE802.3ab. This kind of media converter supports two types of media network connections: 10Base-T/100Base-TX/1000Base-T and 1000Base-SX/LX. MC201 can conduct mutual conversion between 10Base-T/100Base-TX/1000Base-T twisted pair electrical signals and 1000Base-SX/LX optical signals.
Introduction
MC201, 10/100/1000Mbps adaptive Gigabit Ethernet fiber converter uses the switching technology to conduct media conversion, which meets the standards of IEEE802.3, IEEE802.3u, IEEE802.3z and IEEE802.3ab. This kind of media converter supports two types of media network connections: 10Base-T/100Base-TX/1000Base-T and 1000Base-SX/LX. MC201 can conduct mutual conversion between 10Base-T/100Base-TX/1000Base-T twisted pair electrical signals and 1000Base-SX/LX optical signals. This media converter extends the transmission distance of a network from 100m over copper wires to 20 Km. This media converter supports transmission in dual-fiber multi-mode, dual-fiber single-mode, single-fiber single-mode, SC/ST/FC style fiber-optic connections.
Features
1. Accord to IEEE802.1 10Base-T, IEEE802.3u 100Base-TX,IEEE802.3ab 1000Base-TX, IEEE802.3z 1000Base-SX/LX
2. MDI/MDI-X auto negotiation, 10M/100M/1000M auto negotiation
3. Supports full /half duplex, Point-to-point transparent transfer
4. Power External 5VDC input
5. Plug-and-play, easy to installation
6. High-performance 1.25Gbps bandwidth.
7. Complies with FCC, 15 CLASS A ,RoHs and CE MARK
8. Can insert to 2U 19″, 14 slots Rackmount(power external)
| Interface | |
| Standards | comply with IEEE802.1 10Base-T, IEEE802.3u 100Base-TX, IEEE 802.3ab 1000Base-TX,IEEE802.3z 1000Base-SX/LX standards |
| RJ45 port rate | 10/100/1000Mbps auto negotiation |
| Optic port rate | 1000Mbps |
| Working mode | Asynchronous, point to point, full/half duplex |
| RJ45port | Transfer distance :100m |
| Fiber optic | 20,40,60,80,100,120km(SM), 550m(MM) optional |
| RJ45 port cable | UTP 5E |
| Fiber connector | SC,ST,FC optional |
| Fiber optic cables | Single Mode:8.3/125,8.7/125,9/125or 10/125 um, Muti-Mode:50/125,62.5/125 um |
| Wavelength | 850nm, 1310nm,1550nm |
| Power | |
| Power supply | External 5VDC input |
| Consumption | 4W |
| Operating temp | -25°C to50°C |
| Storage temperature | -35°C to 70°C |
| Operating humidity | 5% to 95%(no condensation) |
| Dimensions | 110×70×25mm(Power External) |
| Shell | Iron |
| Color | Black |
| Weight | 180g(power external) |
| Warranty | 3 years |
| Approvals | FCC,CE, RoHS approval |
| Model NO. | Description |
| MC201-M-2 | multi-mode, 2Km, 5VDC, SC, FC or ST, optional |
| MC201-S-20 | single-mode, 20Km,5VDC, SC, FC or ST, optional |
| MC201-S-40 | single-mode, 40Km, 5VDC, SC, FC or ST, optional |
| MC201-S-60 | single-mode, 60Km, 5VDC, SC, FC or ST, optional |
| MC201-S-80 | single-mode, 80Km, 5VDC, SC, FC or ST, optional |
| MC201-S-100 | single-mode, 100Km,5VDC, SC, FC or ST, optional |
| MC201-S-120 | single-mode, 120Km, 5VDC, SC, FC or ST, optional |
| MC201-SS-20 | single-mode, single fiber, 20Km, 5VDC, SC, FC or ST, optional |
| MC201-SS-40 | single-mode, single fiber, 40Km, 5VDC, SC, FC or ST, optional |
| MC201-SS-60 | single-mode, single fiber, 60Km, 5VDC, SC, FC or ST, optional |
| MC201-SS-80 | single-mode, single fiber, 80Km, 5VDC, SC, FC or ST, optional |
