2-port 10/100/1000M Ethernet Media Converter

MC202

MC202 complies with IEEE802.3, IEEE802.3u, IEEE802.3x Standards. It is designed to convert data signal between 10/100/1000 Base-TX and 1000Base-FX fast Ethernet. It supports 10/100/1000Base-TX and 1000Base-FX applications. The data signal converted by such high performance media converter can be transmitted up to 120Km maximum by fiber-optical cable. The Converter is equipped one optic port and two RJ45 Jacks and one external power supply receptacle.

Introduction

MC202 complies with IEEE802.3, IEEE802.3u, IEEE802.3x Standards. It is designed to convert data signal between 10/100/1000 Base-TX and 1000Base-FX fast Ethernet. It supports 10/100/1000Base-TX and 1000Base-FX applications. The data signal converted by such high performance media converter can be transmitted up to 120Km maximum by fiber-optical cable. The Converter is equipped one optic port and two RJ45 Jacks and one external power supply receptacle. LED indicators are built-in for easy diagnosing and monitoring the status of. It can be configured automatically for Full Duplex or Half Duplex operation.

Features

1.   Accord to IEEE802.1 10Base-T, IEEE802.3u 100Base-TX, IEEE802.3 1000Base-FX

2.   MDI/MDI-X auto negotiation, 10M/100/1000M auto negotiation

3.   Supports full /half duplex, Point-to-point transparent transfer

4.   Power External 5VDC input

5.   Plug-and-play, easy to installation

6.   High-performance 1.25Gbps bandwidth.

7.   Complies with FCC, 15 CLASS A ,RoHs and CE MARK

8.   Can insert to 2U 19″, 14 slots Rackmount(power external)

Interface
Standards comply  with IEEE802.1 10Base-T, IEEE802.3u 100Base-TX, IEEE 802.3ab 1000Base-TX,IEEE802.3z  1000Base-SX/LX standards
RJ45 port rate 10/100/1000Mbps  auto negotiation
Optic port rate 1000Mbps
Working Asynchronous,  point to point
Transfer distance
RJ45port 100m
Fiber optic 20,40,60,80,100,120km(SM), 2 km(MM) optional
RJ45 port cable UTP 5E
Fiber connector SC,ST,FC optional
Fiber optic cables Single Mode:8.3/125,8.7/125,9/125  or 10/125 um, Muti-Mode:50/125,62.5/125 um
Wavelength 850nm,1310nm,1550nm
Power
Power supply External 5VDC input
Consumption 4W
Environment
Operating temperature -25°C to50°C
Storage temperature -35°C to 70°C
Operating humidity 5% to 95%(no condensation)
Dimensions: 110×70×25mm(Power External)
Shell Iron
Color Black
Weight 180g(power external)
Warranty 3 years
Approvals FCC,CE, RoHS approvals

Model NO. Description
MC202-M-2 multi-mode, 2Km, 5VDC, SC, FC or ST, optional
MC202-S-20 single-mode,  20Km,5VDC, SC, FC or ST, optional
MC202-S-40 single-mode, 40Km, 5VDC, SC, FC or ST, optional
MC202-S-60 single-mode, 60Km,  5VDC, SC, FC or ST, optional
MC202-S-80 single-mode, 80Km, 5VDC, SC, FC or ST, optional
MC202-S-100 single-mode,  100Km,5VDC, SC, FC or ST, optional
MC202-S-120 single-mode, 120Km, 5VDC, SC, FC or ST, optional
MC202-SS-20 single-mode, single  fiber, 20Km, 5VDC, SC, FC or ST, optional
MC202-SS-40 single-mode, single fiber, 40Km, 5VDC, SC, FC or ST,  optional
MC202-SS-60 single-mode, single  fiber, 60Km, 5VDC, SC, FC or ST, optional
MC202-SS-80 single-mode, single fiber, 80Km, 5VDC, SC, FC or ST,  optional

DATA SHEET
