LAPP KABEL ÖLFLEX® H05RN-F
Rubber cable for hand-held devices and light chains or electrical decorations
H05RN-F, HAR, power and control cable, rubber, 300/500 V, class 5/flexible -25°C to +60°C, light mechanical stress, oil-resistant, flame-retardant
Oil-resistant
Benefits
- Type-compliant versions <HAR> certified with the “<HAR>” testing and certification mark for accelerated granting of approvals if final application of cable is within the European CENELEC area
Application range
- According to EN 50565-2: For device connections in households, kitchens or offices under light mechanical stress; hand-held inspection lamps
- According to EN 50565-2: Provided the maximum conductor temperature of +60°C, the maximum outer sheath surface temperature of +50°C and the lack of ozone resistance are taken into account, suitable for permanent use outdoors with conventional mechanical stress
Product features
- Flame-retardant according to IEC 60332-1-2
- Oil-resistant according to EN 60811-404
Norm references / approvals
- <HAR> type certification according to EN 50525-2-21
Design
- Bare copper stranded wire according to HAR standard
- Core insulation: Rubber compound, type EI 4
- Outer sheath: Rubber compound type EM 2
■ Technical data
Classification
- ETIM 5.0 Class-ID: EC001578
- ETIM 5.0 Class-Description: Flexible cable
Core identification code
- Coloured according to HD 308/VDE 0293-308
Conductor design
- Fine wire according to VDE 0295 class 5 / IEC 60228 class 5
Minimum bending radius
- 4 to 8 x outer diameter (EN 50565-1)
Nominal voltage
- U0/U: 300/500 V
Test voltage
- 2000 V
Protective conductor
- G = with GN-YE protective conductor
- X = without protective conductor
Current load capacity
- According to IEC 60364-5-52/ VDE 0298-4
- EN 50565-1/ VDE 0298-565-1
Temperature range
- Flexible use: -25°C to +60°C
| Article number | Number of cores and mm² per conductor | Outer diameter (mm) | Copper index (kg/km) | Weight (kg/km) |
| 1600250 | 2 X 0.75 | 5.7 – 7.4 | 14.4 | 80 |
| 1600252 | 3 G 0.75 | 6.2 – 8.1 | 21.6 | 95 |
| 16002583 | 4 G 0.75 | 6.8 – 8.8 | 28.8 | 105 |
| 1600251 | 2 X 1.0 | 6.1 – 8.0 | 19.2 | 95 |
| 1600253 | 3 G 1.0 | 6.5 – 8.5 | 28.8 | 115 |
