JB-750 yellow |
750V, connection cable for warning indication, flexible, colour coded, meter marking |
- Technical data
-
- Special-PVC connection cable
for warning indication adapted
to DIN VDE 0285-525-2-11 /
DIN EN 50525-2-11 - Temperature range
flexing -15°C to +80°C
fixed installation -40°C to +80°C - Nominal voltage U0/U 450/750 V
- Test voltage 4000 V
- Breakdown voltage min. 8000 V
- Insulation resistance
min. 20 MOhm x km - Minimum bending radius
flexing 7,5x cable Ø
fixed installation 4x cable Ø - Radiation resistance
up to 80×106 cJ/kg (up to 80 Mrad)
- Special-PVC connection cable
- Cable structure
-
- Bare copper-conductor, to
DIN VDE 0295 cl.5, fine-wire,
BS 6360 cl.5, IEC 60228 cl.5 - Core insulation of special PVC
compound type TI2 to
DIN VDE 0207-363-3 / DIN EN 50363-3 - Core identification to DIN VDE 0293
- GN-YE conductor
- Cores stranded in layers with
optimal lay-length - Outer sheath of special PVC
compound type TM2 to
DIN VDE 0207-363-4-1/DIN EN 50363-4-1 - Sheath colour yellow (RAL 1016)
- with meter marking
- Bare copper-conductor, to
- Properties
-
- Extensively oil resistant,
oil-/chemical resistance
see table Technical Informations - The materials used in manufacture are
cadmium-free and contain no silicone
and free from substances harmful to
the wetting properties of lacquers
Tests
- PVC self-extinguishing and flame retardant
acc. to DIN VDE 0482-332-1-2,
DIN EN 60332-1-2, IEC 60332-1 (equivalent
DIN VDE 0472 part 804 test method B)
- Extensively oil resistant,
- Note
-
- G = with green-yellow conductor
- AWG sizes are approximate equivalent
values. The actual cross-section is in mm².
- Application
- These cables are used for flexible use for medium mechanical stresses with free movement without tensile stress or forced movements in dry, moist and wet rooms but not suitable for open air, as connection cable with yellow outer sheath as a special warning indication. Recommendation in accordance to EN 60204 part 1 and DIN VDE 0113 part 1.
CE = The product is conformed with the EC Low-Voltage Directive 2006/95/EC. - Downloads
