JB-750 HMH |
flexible control cable, coloured core, halogen-free, extremely fire resistant, oil resistant1), meter marking |
 |
- Technical data
-
- Halogen free flexible control cable,
adapted to
DIN VDE 0285-525-2-51 /
DIN EN 50525-2-51 and
DIN VDE 0285-525-3-11/
DIN EN 50525-3-11 - Temperature range
flexing -15°C to +70°C
fixed installation -40°C to +70°C - Nominal voltage U0/U 450/750 V
- Test voltage 3000 V
- Minimum bending radius
flexing 12,5x cable Ø
fixed installation 4x cable Ø - Radiation resistance
up to 100×106 cJ/kg (up to 100 Mrad)
- Halogen free flexible control cable,
- Cable structure
-
- Bare copper conductor, to
DIN VDE 0295 cl.5, fine wire,
BS 6360 cl.5, IEC 60228 cl.5 - Core insulation of halogen-free polymer
compound type TI6 to
DIN VDE 0207-363-7 / DIN EN 50363-7 - Core identification to DIN VDE 0293-308
- GN-YE conductor
- Cores stranded in layers with
optimal lay length - Outer sheath of halogen-free polymer
compound type TM7 to
DIN VDE 0207-363-8 / DIN EN 50363-8 - Sheath colour: grey (RAL 7001)
- With meter marking
- LS0H= Low Smoke Zero Halogen
- Bare copper conductor, to
- Properties
-
- ¹) We recommend you for critcal
applications a consultation - The materials used during manufacturing
are cadmium-free, contain no silicone
and are free from substances harmful
to the wetting properties of lacquers
Tests
- Flame test acc. to
DIN VDE 0482-332-3, BS 4066 part 3,
DIN EN 60332-3, IEC 60332-3 (previously
DIN VDE 0472 part 804 test method C) - self-extinguishing and flame retardant
acc. to DIN VDE 0482-332-1-2,
DIN EN 60332-1-2, IEC 60332-1 (equivalent
DIN VDE 0472 part 804 test method B) - Corrosiveness of combustion gases
acc. to DIN VDE 0482 part 267,
DIN EN 50267-2-2, IEC 60754-2
(equivalent DIN VDE 0472 part 813) - Halogen-free acc. to DIN VDE 0482
part 267 / DIN EN 50267-2-1 / IEC 60754-1
(equivalent DIN VDE 0472 part 815) - Smoke density acc. to DIN VDE 0482
part 1034-1+2, DIN EN 61034-1+2,
IEC 61034-1+2, BS 7622 part 1+2
(previously DIN VDE 0472 part 816)
- ¹) We recommend you for critcal
- Note
-
- G = with green-yellow conductor
x = without green-yellow conductor (OZ) - Please note the cleanroom qualification
when ordering. - AWG sizes are approximate equivalent
values.
The actual cross section is in mm². - screened analogue type:
JB-750 HMH-C
- G = with green-yellow conductor
- Application
- Halogen-free, flame retardant cables are used as measuring and control cable in machine tools, conveyor belts, production lines as well as in plant installations, in air-conditioning and steel production works. For fixed installation or flexible application, directed without forcing by casual, not constantly recurring free movements and without tensile stress, for medium mechanical strain. This cable is suitable for the application in dry, damp and wet environments and also for laying on plaster.
CE = Product conforms with Low-Voltage Directive 2014/35/EU. - Downloads
