• Special-PVC control cable adapted
  to DIN VDE 0285-525-2-51 /
  DIN EN 50525-2-51
• Temperature range
  flexing -10°C to +80°C
  fixed installation -40°C to +80°C
• Nominal voltage
  U₀/U 300/500 V
• Test voltage
  3000 V
• Breakdown voltage
  min. 6000 V
• Mutual capacitance
  core/core  approx. 140 nF/km
  core/screen  approx. 187 nF/km
• Inductance
  approx. 0,68 mH/km
• Coupling resistance
  max. 250 Ohm/km
• Minimum bending radius
  flexing 10x cable Ø
  fixed installation 5x cable Ø
• Radiation resistance
  up to 80×10⁶ cJ/kg (up to 80 Mrad)

• Bare copper conductor, to
  DIN VDE 0295 cl.5, fine wire,
  BS 6360 cl.5, IEC 60228 cl.5
• Core insulation of special PVC
  compound type Z 7225
• Core identification to DIN VDE 0293
  black cores with continuous white
  numbering
• without GN-YE conductor
• Cores stranded in layers with
  optimal lay length
• Separating foil
• Tinned copper braided screen,
  approx. 85% coverage
• Outer sheath of special PVC
  compound type TM2 to
  DIN VDE 0207-363-4-1/DIN EN 50363-4-1
• Sheath colour: blue (RAL 5015)
• With meter marking

• Extensively oil resistant,
  oil-/chemical resistance
  see “Technical Informations”
• The materials used during manufacturing
  are cadmium-free, contain no silicone
  and are free from substances harmful
  to the wetting properties of lacquers

Tests

• PVC self-extinguishing and flame retardant
  acc. to DIN VDE 0482-332-1-2,
  DIN EN 60332-1-2, IEC 60332-1-2

• For installation in explosive areas
  including intrinsic safety –i-
  acc. to DIN EN 60079-14 section 16.2.2
  (VDE 0165 part 1)
• Instrumentation cable RE-2Y(St)Yv with blue
  outer sheath see Data and Computer cables
• AWG sizes are approximate equivalent
  values. The actual cross section is in mm².
