Cáp Điều Khiển Hosiwell ( 9216 ) 1x2x16AWG | Audio/Control, Instrument Cable | Chính Hãng – Chống Nhiễu – Giá Tốt Nhất

1 Pair 16 AWG Overall Foill Shielded Paired Cable

CABLE CONSTRUCTION

P/N: 9216

Conductor: Tinned Copper

Insulation: PE (High Density Polyethylene)

Shielding ( Coverage 100%): Aluminum Foil-Polyester Tape

Drain Wire: Tinned Copper

Outer Jacket, Colour : PVC, Grey

– No of Pair: 1

– Jacket Thickness: 0.96 mm

– Conductor Size: 16 AWG, 26 x 30 AWG

– Jacket Diameter: 8.20 ± 0.20 mm

– Insulation Thickness: 0.80 mm

– Max. Recommended  Pulling Tension: 453 N

– Insulation Diameter: 3.15 mm

– Min. Bending Radius Minor Axis: 82 mm

– Drain Wire Size: 18 AWG

– Operation Temperature: -10°C to 75°C

Compliance :

-UL Standard 2092

-NEC Article 725, type CM

-UL 1685 Vertical Tray

-UL Approvals

DATA SHEET
