Cáp Báo Cháy Hosiwell ( PM25002C-LSZH-FR ) 2C x 2.5 mm² | Cu/Mica tape/XLPE/LSZH | Chính Hãng – Chống Cháy – Giá Tốt Nhất
CABLE CONSTRUCTION
P/N: PM25002C-LSZH-FR
Conductor: Plain Annealed Copper
Fire Barrier: Mica Tape
Insulation: XLPE
Binder: Mylar tape wrapping
Outer Jacket, Colour: Low smoke and no halogen LSZH, Orange
Voltage Rate: 600/1000V
Dielectric Strength Between Pairs: 1.5 KV/5min
Temperature Rate: -20°C to 90°C
Min. Bending Radius Minor Axis: 10 x 0.D
Standard: BS 6387 Cat. CWZ
Test Voltage: 2000 V
Compliance :
Construction
– IEC 60228, IEC 60502-1
Circuit integrity
– BS 6387 Categories C, W, Z
– IEC 60331 at 750ºC 3 hours
Flame propagation
– IEC 60332-1
– IEC 60332-3 Categories A, B, C
Acid gas emission
– IEC 60754-2
Smoke emission
– IEC 61034
