Cáp Báo Cháy Hosiwell ( IF10001P-LSZH-FR ) 1x2x1.0 mm² | Cu/Mica tape/XLPE/OSCR/LSZH | Chính Hãng – Chống Cháy – Chống Nhiễu – Giá Tốt Nhất

Fire Resistant Instrumentation Cables Single & Multi Pair

CABLE CONSTRUCTION

P/N: IF10001P-LSZH-FR

Conductor: Plain Annealed Copper

Fire Barrier: Mineral ceramic (Mica) based fire resistant tape, wrapping

Insulation XLPE. Color: Black, White

Binder:  Mylar tape wrapping

Shielding (Coverage 100%) : Aluminum Foil-Polyester Tape

Drain Wire : Tinned Copper Wire

Outer Jacket, Colour: Low smoke and no halogen LSZH, Orange

Voltage Rate:  300/500 V

Dielectric Strength Between Pairs:  1.5 KV/5min

Temperature Rate:  -20°C to 90°C

Min. Bending Radius Minor Axis:  10 x 0.D

Standard: BS 6387 Cat. CWZ

Test Voltage: 2000 V

Compliance :

Construction
– IEC 60228, IEC 60502-1
Circuit integrity
– BS 6387 Categories C, W, Z
– IEC 60331 at 750ºC 3 hours
Flame propagation
– IEC 60332-1
– IEC 60332-3 Categories A, B, C
Acid gas emission
– IEC 60754-2
Smoke emission
– IEC 61034
