ETHERLINE® Cat.5e

Fixed installation

Industrial Ethernet cable Cat.5e for fixed installation; halogenfree or PUR (AWM-approval) outer sheath material, design 2 or 4 x2xAWG24/1

  • Industrial Ethernet cable
  • Cat.5e

Interference signals Mechanical resistance Halogen-free Industrial machinery and plant engineering Automation & fältinstallation



Benefits

  • Seamless communication from the sensor/actuator level to the Internet
  • Screened against interference
  • Can be used in dry or damp rooms
  • Can be used for Industrial Ethernet in harsh industrial environments
  • cables with PUR jacket: 1000 V UL- rating for installation next to power cables

Application range

  • 2pair: 10/100 Mbit/s for Industrial Ethernet
  • 4pair: 10/100/1000 Mbit/s for Industrial Ethernet
  • suitable for EtherCAT and EtherNet/IP applications
  • Industrial use
  • Fixed installation

Product features

  • High-quality, double screening ensures high transmission reliability in areas with electromagnetic interference
  • PUR outer sheath is highly resistant to mineral oils and abrasion
  • Halogen-free outer sheath

Norm references / Approvals

  • PUR versions: UL AWM Style 21576
  • Flame retardant acc. to IEC 60332-1-2
  • Halogen-free according to IEC 60754-1
    (amount of halogen acid gas)
    Corrosiveness of combustion gases according to IEC 60754-2 (degree of acidity)

Product Make-up

  • Solid conductor
  • Core insulation made of foam skin
  • 2 or 4-pair version
  • SF/UTP: braid of tinned copper wire and plastic laminated aluminum foil as overall screening
  • Outer sheath as either PUR or LSZH
  • Colour: water blue (RAL 5021)

Classification

  • ETIM 5.0 Class-ID: EC000830
  • ETIM 5.0 Class-Description: Data cable

Peak operating voltage

  • (not for power applications) 125 V

Minimum bending radius

  • Fixed installation: 7.5 x outer diameter (2 pair cable)
  • Fixed installation: 8 x outer diameter (4 pair cable)

Test voltage

  • Core/core: 1000 V
  • Core/screen: 500 V

Characteristic impedance

  • 100 Ω ± 15%

Temperature range

  • cable with PUR jacket
    Fixed installation: VDE -30°C to +80°C; UL/CSA -30°C to +80°C
    flexing: VDE -5°C to +50°C; UL/CSA -5°C to +80°C
  • cable halogenfree compound
    fixed installation: -30°C to +80°C
    moved: -5°C to +60°C
Article number Article designation Number of pairs and AWG per conductor Outer diameter
(mm)
Copper index (kg/km) Weight (kg/km)
2-pair version
Halogen-free compound
2170280 ETHERLINE® H CAT.5e 2 x 2 x AWG24/1 5,8 22 45
PUR outer sheath, halogen-free
2170281 ETHERLINE® P CAT.5e 2 x 2 x AWG24/1 5,8 22 53
4-pair version
Halogen-free compound
2170296 ETHERLINE® H CAT.5e 4 x 2 x AWG24/1 6,3 32 54
2170298 ETHERLINE® H-H CAT.5e 4 x 2 x AWG24/1 6.0 / 7.5 32 80
Outer sheath: PUR, halogen-free
2170297 ETHERLINE® P CAT.5e 4 x 2 x AWG24/1 6,3 32 62

Accessories
Field-Terminable Connector RJ45 CAT.5e FM45
BUS M12 connectors that can be assembled
Easy connect rail mount adapter Cat.6A
Connector M12 x-coded Cat.6A 10G feldmountable
SMART STRIP stripping tool
DATA STRIP stripping tool
