Cáp Mạng LAPP KABEL ( 2170489 ) 4 x 2 x AWG26/19 | ETHERLINE® FD P CAT.5e | Chính Hãng – Chống Nhiễu – Giá Tốt Nhất
ETHERLINE® Cat.5e FD
Highly flexible application
Industrial Ethernet cable Cat.5e for high flexible use; PUR (AWM-approval) outer sheath material, design 2 or 4 x2xAWG26/19
- Industrial Ethernet cable
- For highly flexible applications
- Only for patch cable applications (max. 60 m)
Benefits
- Seamless communication from the sensor/actuator level to the Internet
- Screened against interference
- Can be used in dry or damp rooms
- Industrial use
- cables with PUR jacket: 1000 V UL- rating for installation next to power cables
Application range
- 2pair: 10/100 Mbit/s for Industrial Ethernet
- 4pair: 10/100/1000 Mbit/s for Industrial Ethernet
- Only for patch cable applications (max. 60 m)
- suitable for EtherCAT and EtherNet/IP applications
- Power chain applications
Product features
- Premium screening against electromagnetic interference
- PUR outer sheath is highly resistant to mineral oils and abrasion
- Halogen-free outer sheath
- cables with PUR jacket: 1000 V UL- rating for installation next to power cables
Norm references / Approvals
- PUR versions: UL AWM Style 21576
- Flame-retardant according IEC 60332-1-2
- Halogen-free according to IEC 60754-1
(amount of halogen acid gas)
Corrosiveness of combustion gases according to IEC 60754-2 (degree of acidity)
Product Make-up
- Bare stranded copper wire, 26AWG (19 x 0.10), (0.14 mm²)
- Inner sheath: thermoplastic elastomer, halogen-free
- 2 or 4-pair version
- Screening: wrapped with braided tinned-copper wires
- PUR outer sheath
- Colour: water blue (RAL 5021)
Classification
- ETIM 5.0 Class-ID: EC000830
- ETIM 5.0 Class-Description: Data cable
Peak operating voltage
- (not for power applications) 125 V
Minimum bending radius
- Fixed installation: 8 x outer diameter
- Flexing: 15 x outer diameter
Test voltage
- Core/core: 1000 V
- Core/screen: 500 V
Characteristic impedance
- 100 Ω ± 15%
Temperature range
- cable with PUR jacket
Fixed installation: VDE -30°C to +80°C; UL/CSA -30°C to +80°C
flexing: VDE -5°C to +50°C; UL/CSA -5°C to +80°C
| Article number | Article designation | Number of pairs and AWG per conductor | Outer diameter (mm) |
Copper index (kg/km) | Weight (kg/km) |
| 2-pair version | |||||
| 2170289 | ETHERLINE® FD P CAT.5e | 2 x 2 x AWG26/19 | 6,1 | 20 | 48 |
| 4-pair version | |||||
| 2170489 | ETHERLINE® FD P CAT.5e | 4 x 2 x AWG26/19 | 6,3 | 27 | 54 |
■ Accessories
▯ Field-Terminable Connector RJ45 CAT.5e FM45
▯ Connector RJ45 CAT.6 Hirose TM21
▯ Connector RJ45 Cat.6A FM for FD-cables
▯ Connector industry RJ45 Cat.6A 10 IP68
▯ SMART STRIP stripping tool
▯ DATA STRIP stripping tool
