ETHERLINE® EC FD Cat.5e
Highly flexible application
The shielded cable is suitable for highly flexible use in demanding industrial environments. It can be used for the internal connection of devices in control cabinets.
- For EtherCAT applications
- For highly flexible industrial
applications - Cat.5e-Performance
Benefits
- Can be used for Industrial Ethernet in harsh industrial environments
- Can be used in dry or damp rooms
- Lower space requirement
Application range
- suitable for EtherCAT and EtherNet/IP applications
- For highly flexible applications (power chains, moving machine parts)
- Many applications with Industrial Ethernet, e.g. EtherCat, i.e. fixed installation, flexible and highly flexible use
- For internal wiring of electric and electronic equipment in switch cabinets
- Only for patch cable applications (max. 60 m)
Product features
- PUR outer sheath, halogen-free
- Meets the requirements according to Cat. 5e and class D
- High-quality, double screening ensures high transmission reliability in areas with electromagnetic interference
Norm references / Approvals
- UL/CSA type CMX in accordance with UL 444 and CSA C22.2 no. 214-02
- Flame-retardant according to UL VW1/CSA FT1
- Halogen-free according to VDE 0472-815
Product Make-up
- tinned stranded copper wire, 26AWG (19 x 0.10), (0.14 mm²)
- Core insulation: PE
- insulation colour-codes: orange/white-orange; green/white-green
- Star quad
- SF/UTP: braid of tinned copper wire and plastic laminated aluminum foil as overall screening
- Outer sheath: PUR compound, halogen-free
- Colour: green (based on RAL 6018)
Classification
- ETIM 5.0 Class-ID: EC000830
- ETIM 5.0 Class-Description: Data cable
Peak operating voltage
- max. 100 V (not for power applications)
Minimum bending radius
- Fixed installation: 4 x Outer diameter
- Flexing: 16 x outer diameter
Characteristic impedance
- 100 Ω ± 15%
Temperature range
- Fixed installation: -40°C to +80°C
- Flexing: -30°C to +50°C
| Article number | Article designation | Number of pairs and AWG per conductor | Outer diameter (mm) |
Copper index (kg/km) | Weight (kg/km) |
| 2170432 | ETHERLINE® P EC FD Cat.5e | 1 x 4 x AWG26/7 | 5 | 20 | 35 |
■ Accessories
▯ Field mountable S/A connectors M8
▯ Field-Terminable Connector RJ45 CAT.5e FM45
▯ BUS M12 connectors that can be assembled
