ETHERLINE® PN Cat.5 FD
Highly flexible application
Industrial Ethernet cable Cat.5 for highflexible use, for PROFINET-applications Type C; design 2x2xAWG22/7; UL- approval
- Highly flexible application
- For PROFINET applications
Benefits
- Can be used in dry or damp rooms
- Screened against interference
- Can be used for Industrial Ethernet in harsh industrial environments
- 2pair: 10/100 Mbit/s for Industrial Ethernet
Application range
- Power chain applications
- Wiring of machines, tools, devices, appliances and control cabinets
- max. cable lenght für 100 Mbit/s is 85 m
- suitable for EtherCAT and EtherNet/IP applications
Product features
- CAT.5-Performance
- PUR outer sheath is highly resistant to mineral oils and abrasion
- Flame-retardant according IEC 60332-1-2
- Optimized cable construction for power chain use
- Broad usages due to halogen-free materials
Norm references / Approvals
- UL/CSA type CMX (UL 444)
Product Make-up
- Fine-wire strand made of tinned-copper wires
- Star quad
- Colour-coded in accordance with PROFINET for Cat.5 apllications
- Inner sheath: thermoplastic copolymer (FRNC)
- Overall screening with copper braid and plastic-laminated aluminium foil
- PUR outer sheath, halogen-free
- Colour: green (based on RAL 6018)
Classification
- ETIM 5.0 Class-ID: EC000830
- ETIM 5.0 Class-Description: Data cable
Peak operating voltage
- (not for power applications) 125 V
Minimum bending radius
- Moved: 10 x outer diameter
- Fixed installation: 5 x outer diameter
Test voltage
- Core/core: 700 V
- Core/screen: 700 V
Characteristic impedance
- 100 Ω ± 15%
Temperature range
- Fixed installation: -30°C to +70°C
- Flexing: -20°C to +60°C
| Article number | Article designation | Number of pairs and AWG per conductor | Outer diameter (mm) |
Copper index (kg/km) | Weight (kg/km) |
| For highly flexible applications (7-wire stranded conductor) = type C | |||||
| 2170894 | ETHERLINE® FD P FC CAT.5 | 2 x 2 x AWG22/7 | 6.5 | 31.3 | 63 |
