ETHERLINE® Cat.5 FRNC HYBRID
Flexible use
Industrial Ethernet cable Cat.5 with cores for power supply for flexible use; PUR outer sheath, design 2x2xAWG22/7 +4x 1,5; AWM- approval
HYBRID: cable for data transmission + power supply
Benefits
- Industrial use
- Screened against interference
Application range
- Industrial Ethernet cable
- 2pair: 10/100 Mbit/s for Industrial Ethernet
- High-quality, double screening ensures high transmission reliability in areas with electromagnetic interference
- max. cable lenght für 100 Mbit/s is 85 m
- suitable for EtherCAT and EtherNet/IP applications
Product features
- Flame-retardant according IEC 60332-1-2
- HYBRID: cable for data transmission + power supply
- Robust, halogen-free outer sheath
- CAT.5-Performance
Norm references / Approvals
- UL AWM Style 21282
Product Make-up
- Cores for Power Supply
4 x 1.5 mm2 (AWG16) - Data transfer: braided conductor, 7-wire, bare
- Pair screening: wrapped with foil and braided copper wires
- Twisting: data pairs and power supply pairs twisted together
- Overlapping plastic tape
- FRNC outer sheath
- Colour: green (based on RAL 6018)
Classification
- ETIM 5.0 Class-ID: EC000830
- ETIM 5.0 Class-Description: Data cable
Minimum bending radius
- Occasional flexing: 10 x outer diameter
- Fixed installation: 5 x outer diameter
Test voltage
- See data sheet
Characteristic impedance
- 100 Ω ± 15%
Temperature range
- Operation: -20 °C to +70 °C
| Article number | Article designation | Number of pairs and AWG per conductor | Outer diameter (mm) |
Copper index (kg/km) | Weight (kg/km) |
| Flexible use | |||||
| 2170887 | ETHERLINE® Cat.5 FRNC HYBRID | 2x2xAWG22/7 + 4×1.5 | 10,3 | 94,2 | 153 |
