ETHERLINE® Cat.6A

Fixed installation

Industrial Ethernet cable Cat.6A for fixed installation; halogenfree, PVC or PUR outer sheath, design 4x2xAWG22/1

  • Industrial Ethernet cable
  • For PROFINET applications with 4 pairs
  • CAT.6Aqualified for 10Gbit/s

UV-resistant Interference signals Mechanical resistance Industrial machinery and plant engineering Automation & fältinstallation



Benefits

  • Can be used in dry or damp rooms
  • Screened against interference
  • Can be used for Industrial Ethernet in harsh industrial environments
  • 4pair: 100Mbit/s up to 10 Gbit/s for Industrial Ethernet

Application range

  • for industrial secondary and tertiary cabling according to EN 50173-3 ISO/IEC 24702
  • Wiring of machines, tools, devices, appliances and control cabinets
  • max. cable lenght for 100 Mbit/s is 100 m
    max. cable lenght for 10 Gbit/s is 100 m
  • suitable for EtherCAT and EtherNet/IP applications

Product features

  • PUR outer sheath is highly resistant to mineral oils and abrasion
  • Robust, halogen-free outer sheath
  • The oil-resistant PVC sheath enables usage in industrial environments
  • High-quality, double screening ensures high transmission reliability in areas with electromagnetic interference

Product Make-up

  • Solid bare copper wire AWG22
  • Core insulation made of polyethylene (PE)
  • S/FTP: copper braid as overall screening and pair screening with aluminium compound foil
  • Colour: green (based on RAL 6018)

Classification

  • ETIM 5.0 Class-ID: EC000830
  • ETIM 5.0 Class-Description: Data cable

Peak operating voltage

  • (not for power applications) 125 V

Minimum bending radius

  • Fixed installation: 10 x outer diameter

Characteristic impedance

  • 100 ohm at 1 – 100 MHz

Temperature range

  • Cable with PUR sheath
    Fixed installation: -40°C to +80°C
  • Cable, halogen-free outer sheath
    Fixed installation: -25°C to +80°C
    Cable with PVC sheath
    Fixed installation: -30°C to +80°C
Article number Article designation Number of pairs and AWG per conductor Outer diameter
(mm)
Copper index (kg/km) Weight (kg/km)
Outer sheath: halogen-free, flame-retardant compound
2170466 ETHERLINE® Cat.6A H 4 x 2 x AWG22/1 8,7 53 99
Outer sheath: PUR, halogen-free
2170465 ETHERLINE®CAT.6A P 4 x 2 x AWG22/1 8,7 53 91
Outer sheath: PVC
2170464 ETHERLINE® Cat.6A Y 4 x 2 x AWG22/1 8,7 53 98

Accessories
Easy Connect RJ45 Modul Cat.6A 10G
Connector RJ45 Cat.6A feldmountable
Connector M12 x-coded Cat.6A 10G feldmountable
DATA STRIP stripping tool
