ETHERLINE® TORSION Cat.6A
Highly flexible application
Industrial Ethernet cable Cat.6A for torsion stress applications (±180°); 4 pairs, PVC or PUR outer sheath with CMX approval; design 4x2xAWG24/7; PROFINET type C
- Industrial Ethernet Cable, 4-pair, suitable for torsion stress
- CAT.6A qualified for 10Gbit/s
- For PROFINET applications
Benefits
- Many applications with Industrial Ethernet, e.g. PROFINET, i.e. fixed installation, flexible use as well as TORSION.
- 4pair: 100Mbit/s up to 10 Gbit/s for Industrial Ethernet
- Premium screening against electromagnetic interference
- Can be used for Industrial Ethernet in harsh industrial environments
Application range
- Suitable for torsional applications which are typical for the loop in wind turbine generators (WTG)
- Can be used for Industrial Ethernet in harsh industrial environments
- max. cable lenght für 100 Mbit/s is 85 m
- max. cable length for 10 Mbit/s is 85 m
- suitable for EtherCAT and EtherNet/IP applications
Product features
- PUR version is halogen-free according to IEC 60754
- Oil-resistant acc. IEC 60811-2-1
- Cable suitable for high torsion. Tested with more than 1 million bending cycles and a right/left movement of 180° per metre
- Meets the requirements according to CAT.6A, ISO/IEC 11801 and EN 50173
Norm references / Approvals
- electrical requirements acc. to IEC 61156-6
- PUR: UL/CSA-certified (CMX)
- PUR versions: UL AWM Style 21576
- PVC cable is UL/CSA-certified (CM)
- Flame retardant acc. to IEC 60332-1-2
Product Make-up
- 7-wire tinned stranded copper conductor
- Core insulation made of polyethylene (PE)
- S/FTP: copper braid as overall screening and pair screening with aluminium compound foil
- Outer sheath: PUR, halogen-free/PVC
- Colour: green (based on RAL 6018)
Classification
- ETIM 5.0 Class-ID: EC000830
- ETIM 5.0 Class-Description: Data cable
Minimum bending radius
- Flexing: 15 x outer diameter
- Fixed installation: 8 x cable diameter
Characteristic impedance
- 100 Ohm
Temperature range
- Fixed installation
PVC: -40°C to +80°C
PUR: -40°C to +80°C - Flexing
PVC: -10°C to +70°C
PUR: -30°C to +70°C
| Article number | Article designation | Number of pairs and AWG per conductor | Outer diameter (mm) |
Copper index (kg/km) |
| PVC sheath | ||||
| 2170482 | ETHERLINE® TORSION Y CAT6A | 4 x 2 x AWG24/7 | 9 | 44 |
| Outer sheath: PUR, halogen-free | ||||
| 2170483 | ETHERLINE® TORSION P CAT6A | 4 x 2 x AWG24/7 | 9 | 44 |
