ETHERLINE® Cat.7
Fixed installation
Industrial Ethernet cable Cat.7 for fixed installation; halogenfree, PVC or PUR outer sheath, design 4x2xAWG22/1
- Industrial Ethernet cable
- For PROFINET applications with 4 pairs
- Cat.7 qualified for 10Gbit/s
Benefits
- Can be used in dry or damp rooms
- Screened against interference
- Can be used for Industrial Ethernet in harsh industrial environments
- 4pair: 100Mbit/s up to 10 Gbit/s for Industrial Ethernet
Application range
- for industrial secondary and tertiary cabling according to EN 50173-3 ISO/IEC 24702
- Wiring of machines, tools, devices, appliances and control cabinets
- max. cable lenght for 100 Mbit/s is 100 m
max. cable lenght for 10 Gbit/s is 100 m - suitable for EtherCAT and EtherNet/IP applications
Product features
- PUR outer sheath is highly resistant to mineral oils and abrasion
- Robust, halogen-free outer sheath
- The oil-resistant PVC sheath enables usage in industrial environments
- High-quality, double screening ensures high transmission reliability in areas with electromagnetic interference
Product Make-up
- Solid bare copper wire AWG22
- Core insulation made of polyethylene (PE)
- S/FTP: copper braid as overall screening and pair screening with aluminium compound foil
- Colour: green (based on RAL 6018)
Classification
- ETIM 5.0 Class-ID: EC000830
- ETIM 5.0 Class-Description: Data cable
Peak operating voltage
- (not for power applications) 125 V
Minimum bending radius
- Fixed installation: 10 x outer diameter
Characteristic impedance
- 100 ohm at 1 – 100 MHz
Temperature range
- fixed installation
PVC: -30°C to +80°C
PUR: -40°C to +80°C - cable halogenfree compound
Fixed installation: -25°C to +80°C
| Article number | Article designation | Number of pairs and AWG per conductor | Outer diameter (mm) |
Copper index (kg/km) | Weight (kg/km) |
| Halogen-free jacket | |||||
|
2170476 |
ETHERLINE® Cat.7 H | 4 x 2 x AWG22/1 | 9 | 53 | 99 |
| PUR outer sheath, halogen-free | |||||
|
2170475 |
ETHERLINE® Cat.7 P | 4 x 2 x AWG22/1 | 9 | 53 | 91 |
| PVC outer sheath | |||||
|
2170474 |
ETHERLINE® Cat.7 Y | 4 x 2 x AWG22/1 | 9 | 53 | 98 |
