ETHERLINE® HEAT 6722
Industrial Ethernet cable with halogenfree PUR-jacket, tested acc. to ECE-R 118.01, designed acc.to requirements of ISO 6722, Cat.5e up to Cat.7 cables
- Designed according to ISO 6722
- tested acc.to ECE-R 118.01
Benefits
- Easy to strip and dismantle
- Extended temperature range
- Good resistance to oil, petrol, acids and alkalis
- Abrasion and cut-resistant, halogen-free, oil-resistant
- Reduction of flame propagation, density and toxicity of smoke gases in event of fire
Application range
- For flexible applications (7-wire stranded conductor)
- For fixed, flexible and protected installations inside buses
- Suitable for connecting to of e.g. camera systems, enter-/ infotainment for passengers, ticketing systems
- 4pair: 100Mbit/s up to 10 Gbit/s for Industrial Ethernet
Product features
- Halogen-free according to VDE 0472-815
- Good chemical resistance
- Flame retardant acc. to ISO 6722-1
- temperature class B on the basis of ISO 6722-1
Norm references / Approvals
- DIN/ISO 6722
- electrical requirements acc. to IEC 61156-6
- tested acc.to ECE-R 118.01
- ISO 14572, 5.21
- LV 112-1, LV 212-2, LV 213-2
Product Make-up
- Stranded tinned 7-wire conductor
- Core insulation: Based on Polyolefin
- Colour-coded in accordance with EIA/TIA 568A and B
- Cat.5e: SF/UTP – copper braid and foil screening as overall screening
- Cat.6A/Cat.7: S/FTP – copper braid as overall screening and pair screening with aluminium compound foil
- Outer sheath: PUR compound, halogen-free
- outer sheath colour:
Cat.5e green (RAL 6018)
Cat.6A yellow (RAL 1003)
Cat.7 blue (RAL 5021)
Classification
- ETIM 5.0 Class-ID: EC000830
- ETIM 5.0 Class-Description: Data cable
Peak operating voltage
- (not for power applications) 125 V
Minimum bending radius
- Flexing: 15 x outer diameter
- Fixed installation: 10 x outer diameter
Characteristic impedance
- nom. 100 Ω acc. to IEC 61156-6
Temperature range
- Flexing: -30 °C to +105 °C
Fixed installation: -40 °C to +105 °C
| Article number | Article designation | Number of pairs and AWG per conductor | Outer diameter [mm] | Copper index (kg/km) | Weight (kg/km) |
| 2170850 | ETHERLINE® Cat. 5e FL9YBC11Y 4x2x0,22sn | 4x2xAWG24/7 | 7.7 | 38 | 72 |
| 2170581 | ETHERLINE® Cat. 6A FL09YBC11Y 4x2x0,22sn | 4x2xAWG24/7 | 8.1 | 38 | 77 |
| 2170582 | ETHERLINE® Cat. 7 FL09YBC11Y 4x2x0,22sn | 4x2xAWG24/7 | 8.1 | 38 | 77 |
