UNITRONIC® LAN 200 Cat.5e
Ethernet cable for Category 5e/ class D – verfied up to 200 MHz
The LAN cable is used particular in places with a high density of terminal devices, for example in building wiring networks. The cable transmits the digital and analogue signals.
CPR: Article number choice under www.lappkabel.com/cpr
Benefits
- LAN cables for structured building cabling according to EN 50173 and ISO/IEC 11801
Application range
- Mainly used where the terminal density is very high, e.g. for wiring office, administration and development buildings in the tertiary area (floor wiring).
- Cable length in tertiary area (horizontal area, floor) should not exceed a length of 100 m in accordance with the ISO/IEC 11801 and EN 50173 standards (90 m in cable duct + 10 m in working area)
Product features
- Transfer of digital and analogue data signals
- IEEE 802.3: 10/100/1000Base-T
IEEE 802.5: ISDN; FDDI; ATM - Flame retardant acc. to IEC 60332-1-2
2170138: flame retardant acc. to IEC 60332-1-2 and IEC 60332-3-24
Norm references / Approvals
- LAN CAT.5e cables from Lapp Kabel for “Structured Cabling Systems” meet the requirements in accordance with EIA/TIA-568 and TSB36, as well as ISO/IEC 11801 or EN 50173 (Class D).
Product Make-up
- Solid conductor
- U/UTP: no overall or pair screening
- F/UTP: foil screening as overall screening
- SF/UTP: braid of tinned copper wire and plastic laminated aluminum foil as overall screening
- outer sheath either as PVC or LSZH (color grey RAL 7035)
■ Accessories
▯ Connector RJ45 CAT.5 Hirose TM11
▯ Connector RJ45 CAT.5 Stewart SS37
▯ Field-Terminable Connector RJ45 CAT.5e FM45
▯ DATA STRIP stripping tool
