HITRONIC® HQA Aerial Cable
Outdoor self-supporting aerial cable with stranded loose tubes and non-metallic strain relief; ADSS cable type
HITRONIC® HQA ADSS cable (All-Dielectric Self-Supporting), non-metallic, ideal in distribution as well as transmission environments; A-DQ(ZN)2Y
Benefits
- Suitable for mild weather conditions
- Easy to install due to the compact design, high flexibility, robust sheath and small bending radii
- UV-resistant
longitudinally and laterally watertight - Zero electromagnetic interference as the cable contains no metal (totally dielectric)
Application range
- For outdoor use
- Hanging on poles
- Laying on poles
- Installation on building columns
Product features
- Stranded loose tubes with up to 96 fibres
- Colour-coded fibres and loose tubes
- Mechanical support members (central filler and aramid yarns)
- Robust, halogen-free outer sheath
- Span width up to 90m
Product Make-up
- Up to 8 stranded gel-filled loose tubes
- Central GRP strength element
- Aramid yarns as strain relief
- PE outer sheath
- Colour: black (RAL 9005)
Classification
- ETIM 5.0 Class-ID: EC000034
- ETIM 5.0 Class-Description: Fibre optic cable
Dimensions
- Primary coated fibre: 250µm
- Cable: see table
Core identification code
- Fibre colour code see
data sheet
Fibre type
- GOF – Glass Optical Fibre
Standard designation
- A-DQ(ZN)2Y – ADSS
- All-Dielectric Self-Supporting
Optical values
- see data sheet
Optical fibre type
- Core material: glass
- Cladding material: glass
Permissible bending radius
- Static: ≥ 15 x outer diameter
- Dynamic: ≥ 20 x outer diameter
Permissible tensile force
- MAT: 2000 N
- EDS: 800 N
Temperature range
- Fixed installation: -40°C to +70°C
- Occasional flexing: -30°C to +70°C
| Article number | Article designation | Fibre type | Number of fbres | Outer diameter (mm) | Weight (kg/km) |
| Single-mode E 9 OS2 | |||||
| 26640912 | HITRONIC® HQA800 6x2E 9/125 OS2 | 9/125 OS2 | 12 | 9,7 | 73 |
| 26640924 | HITRONIC® HQA800 6x4E 9/125 OS2 | 9/125 OS2 | 24 | 9,7 | 73 |
| 26640948 | HITRONIC® HQA800 6x8E 9/125 OS2 | 9/125 OS2 | 48 | 10,9 | 92 |
| 26640972 | HITRONIC® HQA800 6x12E 9/125 OS2 | 9/125 OS2 | 72 | 10,9 | 94 |
| 26640996 | HITRONIC® HQA800 8x12E 9/125 OS2 | 9/125 OS2 | 96 | 12,4 | 121 |
