HITRONIC® HQA-Plus Aerial Cable

Outdoor self-supporting aerial cable with stranded loose tubes, non-metallic strain relief and PE inner and outer sheath; ADSS cable type

HITRONIC® HQA ADSS plus cable, non-metallic, for outside plant aerial, double outer sheath; A-DQ2Y(ZN)2Y

Waterproof UV-resistant Optimum strain relief Low weight Mechanical resistance Halogen-free

Benefits

  • Designed to withstand harsh weather conditions
  • Easy to install due to the compact design, high flexibility, robust sheath and small bending radii
  • UV-resistant
    longitudinally and laterally watertight
  • Zero electromagnetic interference as the cable contains no metal (totally dielectric)

Application range

  • For long span widths
  • Hanging on poles
  • For outdoor use
  • Laying on poles
  • Installation on building columns

Product features

  • Stranded loose tubes with up to 96 fibres
  • Colour-coded fibres and loose tubes
  • Mechanical support members (central filler and aramid yarns)
  • Robust, halogen-free outer sheath
  • Span width up to 250m

Product Make-up

  • Up to 8 stranded gel-filled loose tubes
  • Central GRP strength element
  • Aramid yarns as strain relief
  • PE inner and outer sheaths
  • Colour: black (RAL 9005)

Classification

  • ETIM 5.0 Class-ID: EC000034
  • ETIM 5.0 Class-Description: Fibre optic cable

Dimensions

  • Primary coated fibre: 250µm
  • Cable: see table

Core identification code

  • Fibre colour code see
    data sheet

Fibre type

  • GOF – Glass Optical Fibre

Standard designation

  • A-DQ2Y(ZN)2Y ADSS
  • All-Dielectric Self-Supporting

Optical values

  • see data sheet

Optical fibre type

  • Core material: glass
  • Cladding material: glass

Permissible bending radius

  • Static: ≥ 15 x outer diameter
  • Dynamic: ≥ 20 x outer diameter

Permissible tensile force

  • MAT: 8000 N
  • EDS: 3200 N

Temperature range

  • Fixed installation: -40°C to +70°C
  • Occasional flexing: -30°C to +70°C
Article number Article designation Fibre type Number of fbres Outer diameter (mm) Weight (kg/km)
Single-mode E 9 OS2
26644912 HITRONIC® HQA-Plus3200 6x2E 9/125 OS2 9/125 OS2 12 12,8 132
26644924 HITRONIC® HQA-Plus3200 6x4E 9/125 OS2 9/125 OS2 24 12,8 132
26644948 HITRONIC® HQA-Plus3200 6x8E 9/125 OS2 9/125 OS2 48 13,7 151
26644972 HITRONIC® HQA-Plus3200 6x12E 9/125 OS2 9/125 OS2 72 13,7 153
26644996 HITRONIC® HQA-Plus3200 8x12E 9/125 OS2 9/125 OS2 96 15,3 188
