ADC Structured Cabling Solutions
Category 6 4-pair UTP Cable
This Category 6, UTP 4 -pair cable is an unscreened cable with PVC outer sheath, for use in high
speed data communication. With internationally defined physical and electrical performance up to
250MHz.
Specifications
Conductor: …………………………………………………………….24 AWG copper
Insulation: ……………………………………………………………..Polyethylene
Jacket: ……………………………………………………………………PVC
Outside diameter ……………………………………………………..6.0 mm nominal
Complies with:
ISO11801
TIA/EIA 568-B.2
IEC332-3
Mechanical Characteristics:
Minimum bending radius:
– During installation: ………………………………………………… 50mm
– After installation: ……………………………………………………… 25mm
Maximum pulling tension: ……………………………………………. 108N (11kg)
Box weight, full, nominal: ……………………………………………… 14kg
Thermal Characteristics:
Operation: ……………………………………………………………………. -15°C to 70°C
Installation: ……………………………………………………………………. 5°C to 40°C
Electrical Characteristics:
Conductor DC resistance @ 20°C (max): ……………………………. 9.38Ω/100m
DC resistance unbalance (max): ………………………………………….. 5%
Mutual capacitance @ 20°C (max):………………………………………. 5.6nF/100m
NVP Setting ……………………………………………………………………….. 70%
| Freq | Attenuation | Pr-Pr NEXT |
Power Sum NEXT |
Return Loss |
Pr-Pr ELFEXT |
Power Sum ELFEXT |
Pr-Pr ACR |
Power Sum ACR |
| (MHz) | (dB/100m) | (dB/100m) | (dB/100m) | (dB/100m) | (dB/100m) | (dB/100m) | (dB/100m) | (dB/100m) |
| 1 | 2 | 74,3 | 72,3 | 20 | 67,8 | 64,8 | 72,3 | 70,3 |
| 4 | 3,8 | 65,3 | 63,3 | 23 | 55,8 | 52,8 | 61,5 | 59,5 |
| 8 | 5,3 | 60,8 | 58,8 | 24,5 | 49,7 | 46,7 | 55,5 | 53,5 |
| 10 | 6 | 59,3 | 57,3 | 25 | 47,8 | 44,8 | 53,5 | 51,3 |
| 16 | 7,6 | 56,2 | 54,2 | 25 | 43,7 | 40,7 | 48,6 | 46,6 |
| 20 | 8,5 | 54,8 | 52,8 | 25 | 41,8 | 38,8 | 46,3 | 44,3 |
| 25 | 9,5 | 53,3 | 51,3 | 24,3 | 39,8 | 36,8 | 43,8 | 41,8 |
| 31,25 | 10,7 | 51,9 | 49,9 | 23,6 | 37,9 | 34,9 | 41,2 | 39,2 |
| 62,5 | 15,4 | 47,4 | 45,4 | 21,5 | 31,9 | 28,9 | 32 | 30 |
| 100 | 19,8 | 44,3 | 42,3 | 20,1 | 27,8 | 24,8 | 24,5 | 22,5 |
| 200 | 29 | 39,8 | 37,8 | 18 | 21,8 | 18,8 | 10,8 | 8,8 |
| 250 | 32,8 | 38,3 | 36,3 | 17,3 | 19,8 | 16,8 | 5,5 | 3,5 |
| Description | Quantity | Colour | Product No. |
| Category 6 4-pair Solid UTP Cable Category 6 4-pair Solid UTP Cable |
305m reel 305m reel |
Grey Blue |
6499 1 030-01 6499 1 030-03 |
DATA SHEET
