48-port Category 6 patch panel A/B
An integral part of the ADC Structured Cabling channel solution, the Category 6 patch panels
optimize signal strength and deliver zero bit-error performance using impedance matched
technology. Designed for mounting in standard EIA 19-inch racks or to hinged wall-mount
brackets, their high-density, superior reliability and numerous labelling options make these patch
panels a superior choice for high-performance networks.
Features:
• Performance exceeds TIA/EIA Category 6 requirements
• Designed for Gigabit Ethernet transmission
• Includes rear wire manager
• Conductors can be terminated with either a KRONE Insertion or 110 tool
• UL 1863 listed and Category 6 performance verified
• Forty-five degree silver-plated IDCs provide secure, reliable gas-tight connection
• Includes paper labels or silk-screened area for port identification
• Universal wiring label for easy termination of either T568A/B
Specifications
Operating Temperature Range: …………………………………….. -40º to 70 ºC (-40º to 158 ºF)
RJ Socket, 8 Positions, General Specification: ……………….. FCC Part 68.500 (IEC 60603-7)
Transmission Performance and Reliability: ………………………..≥ EIA/TIA 568-B.2-1 Category 6
…………………………………………………………………………………… ≥ ISO 11801 Class E Standard
Number of Plug Insertion Cycles: …………………………………………….≥ 750
LSA-PLUS® Insulation Displacement
Wire Diameter Range for Solid and ……………………………………. 22-26 AWG
Stranded Copper Conductors: ………………………………………. 0.40 mm to 0.65 mm (0.016″ to 0.025″)
Wire Insulation Diameter Range (PE,PVC): ………………………. 0.70 mm to 1.70 mm (0.028″ to 0.067″)
LSA-PLUS® Contact Resistance: ……………………………………………….. ≤ 1 mΩ typical
Contact Re-terminations: ………………………………………………………………≥ 200
Insulation Resistance at 40 ºC (104 ºF) and 93% RH:……………………. ≥ 500 MΩ
Safety Rating: ………………………………………………………………………. UL 1863
Flammability Rating: …………………………………………………………. UL 94 V-0
| Description | Dimensions (HxWxD) | Product No. |
| 24-port patch panel with snap-in port ID tabs and paper labels, T568A/B compatible 48-port patch panel with snap-in port ID tabs and paper labels, T568A/B compatible |
44.45 mm x 482.6 mm x 38.1 mm (1.75″ x 19″ x 1.5″) 88.9 mm x 482.6 mm x 38.1 mm (3.5″ x 19″ x 1.5″) |
6653 1 679-24 6653 1 679-48 |
DATA SHEET
