6089 1 121-02

LSA PROFIL® Disconnection Module
Features
• Based on genuine KRONE® LSA-PLUS®
connection technology
• Fits on all LSA-PLUS back mount frames, as
well as on PROFIL frames
• Suitable for use in all xDSL and ADSL 2+
circuits
• Flexible indoor and outdoor use
• Robust long-term environmental stability
• Supports all LSA-PLUS Series 2 accessories
– Overvoltage protection
– Labels
– Test and connection cords

Specifications

Electrical values

Insulation resistance:……………. >50 GΩ @ 500 V

Contact resistance: ……………1 mΩ

Safety classification (EN 60950)

Transient voltage: ……………..2.5k V

Operation voltage for basic insulation: …………….210VDC TNV

Pollution severity:…………………….. II

Current-carrying capacity: ……………………2 A

Impulse current:…………………….. 5 kA (8/2µs)

Conductor diameter/outer diameter of connectable wires

Single solid wire per contact: …………………0.35mm/0.68mm to 0.9mm/1.5mm

……………………………………………………………. AWG 26 to AWG 20

Stranded wires (7 tin-coated copper strands): ……………0.12mm to 0.32mm/up to 2.1mm (depending on insulation type)

…………………………………………………………… AWG 28 to AWG 20

Overall diameter of connectable wires …………………………0.68mm to 1.6mm

(solid insulation)

Properties

Connection frequency: ………………….200 times

Plug-in cycles: ………………………….250

Temperature

Storage (EN 60721-3-1): ……………………1K5 (-40° C to +90° C)/1Z1/1B1/1C1/1S1/1M2

Transport (EN 60721-3-2):……………….. 2K2 (-40° C to +90° C)/2B1/2C1/2S1/2M2

Operation (EN 60721-3-3): ……………….3K5 (-5° C to +60° C)/3Z1/3B1/3C1/3S1/3M2

Relative humidity: …………………………..95%; no water condensation, no ice

Materials

Plastics: …………………………….PBT; resistant against aggressive chemicals (PVC-softener)

Plastics flammability class:……………. UL94V-0

Halogen free according to: ……………RoHS, European Directive 2002/96/EG

Contact: ……………………….Special brass, silver-plated

Description Catalogue number
LSA PROFIL 10-pair disconnection module
Colour: White
6089 1 121-02
