IndustrialNet™ Category 5e U/UTP Copper Cable
Category 5e U/UTP copper cable shall meet or exceed the IEC 61156-6 and ANSI/TIA-568-C.2 Category 5e standards up to 80 meters. The stranded copper conductors shall be 24/7 AWG with high density polyethylene (HDPE) insulation. The copper conductors shall be twisted in pairs. All pairs shall then be surrounded by a PVC jacket. The jacket shall be oil, UV, and abrasion resistant for enhanced chemical resistance and mechanical performance. The jacket shall be flame retardant (CM) for industrial Ethernet applications.
Technical information
| Color | Black |
| AWG Size | 24 |
| Length (ft.) | 1000 |
| Length (m) | 305 |
| Nominal Diameter (In.) | 0.248 |
| Nominal Diameter (mm) | 6.3 |
| Jacket Material | PVC |
| No. of Pairs | 4 |
| Packaging Type | Reel |
| CE Compliant | No |
| Application | 10BASE-T (Ethernet), 100BASE-T (Fast Ethernet), 1000BASE-T (Gigabit Ethernet), Industrial Ethernet, Ethernet/IP, Downlinks from control panel to the machine area, Uplinks featuring gigabit data transmission, from the control panel to the consolidation point |
| Cable Type | U/UTP |
| Flammability Rating | CM |
| Insulation Diameter (In.) | 0.037 – 0.041 |
| Insulation Diameter (mm) | 0.94 – 1.04 |
| Part Features | Third party tested, Descending length cable markings, Packaged on a reel |
| Weight (Kg) | 23/305m |
| Weight (lbs) | 51/1000 ft. |
| RoHS Compliancy Status | Compliant |
key features and benefits
Third party tested
Cable has been tested by an independent laboratory and complies with the electrical standard requirements of IEC 61156-6 Category 5e and ANSI/TIA-568-C.2 Category 5e standards
Reliability
Stranded conductors for standard flex applications and ease of installation; cable jacket shall be oil, UV, and abrasion resistant for enhanced chemical resistance and mechanical performance
Descending length cable markings
Easy identification of remaining cable reduces installation time and cable scrap
Packaged on a reel
Ensures proper performance and provides quick installation
applications
IndustrialNet™ Category 5e U/UTP Copper Cable provides reliability and high performance as an integral component of the end-to-end solution for industrial Ethernet and Ethernet/IP based communications networks. The 4-pair high performance cable ensures highest availability in conditions seen in industrial environments. The cable incorporates a durable PVC jacket and is oil, UV, and abrasion resistant.
Key applications include:
- 10BASE-T (Ethernet)
- 100BASE-T (Fast Ethernet)
- 1000BASE-T (Gigabit Ethernet)
- Industrial Ethernet
- Ethernet/IP
- Downlinks from control panel to the machine area
- Uplinks featuring gigabit data transmission from the control panel to the consolidation point
additional specifications
| Mechanical Test | |||
| Ultimate Breaking Strength | >400 N (90 lbf.) | ||
| Minimum Bend Radius | 4x cable diameter | ||
| Electrical Test | |||
| Nominal Velocity of Propagation (NVP) | 65% | ||
| Operating Voltage, Maximum | 80V | ||
