NetKey ® Category 5e U/UTP Copper Cable
Category 5e cable meets ANSI/TIA-568-C.2 Category 5e and ISO 11801 2nd Edition Class D channel standards. The conductors are 24 AWG copper insulated with HDPE polymer. The copper conductors are twisted in pairs and all four pairs are covered by a low smoke zero halogen or flame retardant PVC (CM or CMR) jacket.
Technical information
| Note | Available in EMEA market. |
| AWG Size | 24 |
| Length (ft.) | 1000 |
| Length (m) | 305 |
| Nominal Diameter (In.) | 0.184 |
| Nominal Diameter (mm) | 4.6 |
| Jacket Material | CM – PVC |
| No. of Pairs | 4 |
| Packaging Type | Easy-payout box |
| CE Compliant | No |
| Application | Ethernet 10BASE-T, 100BASE-T (Fast Ethernet), and 1000BASE-T (Gigabit Ethernet), 155 Mb/s ATM, 622 Mb/s, ATM, 1.2 Gb/s ATM, Token ring 4/16 |
| Cable Type | UTP |
| Flammability Rating | PVC (CM) – UL 1685 |
| Part Features | Easy identification of remaining cable, easy payout box, third party tested and Cross Divider that separates twisted pairs for robust cable performance. |
| Weight (Kg) | 8/305m |
| Weight (lbs) | 18/1000 ft. |
| RoHS Compliancy Status | Compliant |
Key features and benefits
Third party tested
Cable has been tested as part of the NetKey ® Category 5e UTP Copper Cabling System by an independent laboratory and complies with the electrical channel requirements of the following standard: ANSI/TIA-568-C.2 Category 5e standard
Descending length cable markings
Easy identification of remaining cable reduces installation time and cable scrap
Easy payout box
Ensures proper performance and provides quick installation
Applications
Applications include:
- Ethernet 10BASE-T, 100BASE-T (Fast Ethernet), and 1000BASE-T (Gigabit Ethernet)
- 155 Mb/s ATM, 622 Mb/s ATM, 1.2 Gb/s ATM
- Token ring 4/16
Additional specifications
| Mechanical Test | |||
| Ultimate Breaking Strength | >400 N (90 lbf.) | ||
| Minimum Bend Radius | 4 x cable diameter | ||
| Electrical Test | |||
| Nominal Velocity of Propagation (NVP) | 65% | ||
