NUL5C04BU-C
Copper cable, category 5e UTP, LSZH, 4-pair, conductors are 24 AWG, twisted in pairs and protected by a low smoke zero halogen jacket, blue.
| AWG Size | 24 |
| Length (ft.) | 1000 |
| Length (m) | 305 |
| Nominal Diameter (In.) | 0.187 |
| Nominal Diameter (mm) | 4.7 |
| Jacket Material | LSZH – Low Smoke Zero Halogen |
| No. of Pairs | 4 |
| Packaging Type | Easy-payout box |
| CE Compliant | No |
| Application | Ethernet 10BASE-T, 100BASE-T (Fast Ethernet), and 1000BASE-T (Gigabit Ethernet), 155 Mb/s ATM, 622 Mb/s, ATM, 1.2 Gb/s ATM, Token ring 4/16 |
| Cable Type | UTP |
| Flammability Rating | LSZH – IEC 60332-1, 60754-1, 60754-2, 61034-2 |
| Part Features | Easy identification of remaining cable, easy payout box, third party tested and Cross Divider that separates twisted pairs for robust cable performance. |
| Weight (Kg) | 9/305m |
| Weight (lbs) | 20/1000 ft. |
| RoHS Compliancy Status | Compliant |
