Cáp LAPP KABEL ( 3801708 ) UNITRONIC® ST 2919 PP | UL 2919

Data communication systems
Low frequency data transmission cables
Metal foil screened pairs

LAPPKABEL UNITRONIC® ST 2919 PP

• product information ( PDF )

■ Application range

• Suitable for audio, control and instrumenta tion measurements in environments immune to noise

• For use in dry and damp environment

■ Product features

• 100% screen coverage, offers optimum protection against external interference at medium and high frequencies

• Flame retardant in acc. to IEC 60332-1-2

■ Approvals (Norm references)

■ Design

• Multi-wire strands of tinned annealed copper

• PE core insulation

• Twisted pair, individual pair screening of aluminium laminated foil

• Tinned copper drain wire

• PVC outer sheath

• Colour: pebble grey, RAL 7032

Technical Data

Core identification code
black/red, black/white, and black/green
Mutual capacitance
C/C: approx. 98 pF/m
C/S: approx. 181 pF/m
Peak operating voltage
30 V (not for power applications)
Specific insulation resistance
> 2 GOhm x km
Inductivity
approx. 0.65 mH/km
Minimum bending radius
10 x cable diameter
Test voltage
1000 V
Temperature range
-20°C to +80°C
Characteristic impedance
50 Ohm
