PUL5504WHY
Enhanced copper cable, category 5e UTP, low smoke zero halogen (LSZH), 4-pair, conductors are 24 AWG construction with polyethylene insulation, twisted in pairs and placed in a flame-retardant LSZH jacket, white.
| AWG Size | 24 |
| Length (ft.) | 1000 |
| Length (m) | 305 |
| Nominal Diameter (In.) | 0.194 |
| Nominal Diameter (mm) | 4.9 |
| Jacket Material | LSZH – Low smoke zero halogen |
| No. of Pairs | 4 |
| Packaging Type | Easy-payout box |
| CE Compliant | No |
| Application | Ethernet 10BASE-T, 100BASE-T (Fast Ethernet), 1000BASE-T (Gigabit Ethernet), 155 Mb/s ATM, 622 Mb/s ATM, 1.2 Gb/s ATM, Token ring 4/16, Data system |
| Cable Type | U/UTP |
| Flammability Rating | IEC 60332-1, IEC 61034, IEC 60754-1, IEC 60754-2 |
| Part Features | Third party tested, Easy payout box, Descending length cable markings and tested beyond the standards |
| Weight (Kg) | 8.6/305m |
| Weight (lbs) | 19/1000 ft. |
| RoHS Compliancy Status | Compliant |
