SOLARFLEX®-X H1Z2Z2-K NTS |
1500 V DC, EN 50618 with rodent protection |
Technical data
- Temperature range
-40°C to +90°C - Max. temperature at the conductor
+120°C - Nominal voltage
AC 1,0/1,0 kV
DC 1,5/1,5 kV - Test voltage
AC 6,5 kV - Minimum bending radius
fixed installation 5x cable Ø
Cable structure
- Tinned copper conductor, fine wire
acc. to DIN VDE 0295 cl.5 /
BS 6360 cl. 5 / IEC 60228 cl.5 - 1. Core insulation of special
cross-linked compound, black
2. Core insulation of special
cross-linked compound, black - Braiding of stainless steel
single V2A (rodent protection)
Properties
- Double-insulated
- Complies protection class II
- UV-resistant
- Ozone resistant
Tests
- Halogen-free acc. to
EN 50267, IEC 60754 - Flame retardant to IEC 60332-1-2
- Smoke density to IEC 61034
- Weathering/UV-resistance acc. to
EN 50289-4-17 Method A - Ozon resistance acc. to EN 50396
Clause 8.1.3 Methode B
Approvals
- EN 50618
TÜV Rheinland 2 PfG 1990/05.12
TÜV R60115689
Application
The SOLARFLEX®-X is used for cabling solar modules.
CE = Product conforms with Low-Voltage Directive 2014/35/EU.
Downloads
| Part no. | No.cores x cross-sec. mm² |
Outer Ø
app. mm |
Cop. weight kg / km |
Weight
app. kg / km |
AWG-No. |
|---|---|---|---|---|---|
| 17000101 | 1 x 4 | 6,0 | 38,4 | 85,0 | 14 |
| 17000102 | 1 x 6 | 6,8 | 57,6 | 112,0 | 14 |
| 17000103 | 1 x 10 | 8,0 | 96,0 | 158,0 | 14 |
