DATAFLAMM®

halogen-free, meter marking

Technical data

• Halogen-free special data cable
• Temperature range
  flexing +5°C to +70°C
  fixed installation -40°C to +70°C
• Operating peak voltage
  (not for heavy current installation purposes)
  0,14 mm² = 350 V
  ≥ 0,25 mm² = 500 V
• Test voltage
  0,14 mm² = 800 V
  ≥ 0,25 mm² = 1200 V
• Insulation resistance
  min. 2 GOhm x km
• Capacitance
  core/core < 70 nF/km
• Minimum bending radius
  flexing 7,5x cable Ø
  fixed installation 4x cable Ø
• Radiation resistance
  up to 100×10⁶ cJ/kg (up to 100 Mrad)

Cable structure

• Bare copper conductor, fine wire
  to DIN VDE 0812
• Conductor construction:
  0,34 mm² = 7×0,25 mm
• Core insulation of PE
  compound type LD/MD to
  DIN VDE 0819-103 / DIN EN 50290-2-23
• Core identification to DIN 47100,
  without colour repetition
• Cores stranded in layers with
  optimal lay length
• Outer sheath
  compound type HM2 to
  DIN VDE 0207 part 24
• Sheath colour: grey (RAL 7005)
• With meter marking

Properties

• PE-insulated cores, compared with
  PVC-insulated cores, assure a remarkable
  and more favourable capacitance values

Tests

• Halogen-free acc. to
  DIN VDE 0482-754-1,
  DIN EN 60754-1, IEC 60754-1
  (previously DIN VDE 0482-267-2-1)
• Corrosiveness of combustion gases
  acc. to DIN VDE 0482-754-2,
  DIN EN 60754-2, IEC 60754-2
  (previously DIN VDE 0482-267-2-2)
• Halogen-free sheath compound,
  self-extinguishing and flame retardant
  acc. to DIN VDE 0482-332-1-2,
  DIN EN 60332-1-2, IEC 60332-1-2
  (equivalent DIN VDE 0472 part 804
  test method B)

Note

• AWG sizes are approximate equivalent
  values. The actual cross section is in mm².
• Screened analogue type:
  DATAFLAMM®-C

Application

DATAFLAMM^® halogen-free data cables are used as connecting cable for signal, measuring, control, call-announcing and two-way intercom speaking systems, clock installations, electronic weighing equipment and electrical apparatus for office requirements. The cables are suitable for installation in dry, damp and wet environments. These cables are generally installed in telecommunication apparatus and data transmission systems in public buildings, laboratories, trading centres where the freedom from halogen in case of fire and the flame propagation must be avoided. The halogen-free thermoplastic sheath produce neither corrosive nor toxic gases.
CE = Product conforms with Low-Voltage Directive 2014/35/EU.
