PUP5504BU-UY
Enhanced copper cable, category 5e UTP, plenum, 4-pair, conductors are 24 AWG construction with FEP/polyolefin insulation, twisted in pairs and protected by a low smoke, flame-retardant PVC jacket, blue.
| AWG Size | 24 |
| Length (ft.) | 1000 |
| Length (m) | 305 |
| Nominal Diameter (In.) | 0.207 |
| Nominal Diameter (mm) | 5.3 |
| Jacket Material | Plenum – low smoke, flame-retardant PVC |
| No. of Pairs | 4 |
| Packaging Type | Easy-payout box |
| CE Compliant | No |
| Application | Ethernet 10BASE-T, 100BASE-T (Fast Ethernet), 1000BASE-T (Gigabit Ethernet), 115 Mb/s ATM, 622 Mb/s ATM and Token Ring 4/16 |
| Cable Type | U/UTP |
| Flammability Rating | Plenum – NFPA 262 and CSA FT-6 |
| Part Features | Easy payout box, Tested beyond the standards and Descending length cable markings |
| Weight (Kg) | 10.9/305m |
| Weight (lbs) | 24/1000 ft. |
| RoHS Compliancy Status | Compliant |
