RADOX Solar Wire

Solar cable

General :
RADOX Solar cable is manufactured with an electron beam cross–linked insulation and jacket, provides excellent mechanical
and environmental resistance to temperature extremes, oil, ozone, weathering and abrasion. In the case of fire flame retardant
properties limit flame propagation, smoke and toxicity. RADOX Solar cable is extremely flexible with a reduced outer diameter
for demanding space requirements, is easy to strip and possesses a long service life. The double insulated design, as a PV–wire
in accordance to the european (CENELEC HD) standards, allows it to be used also in ungrounded PV installations. This provides
the cost saving option of using RADOX Solar cable without a conduit

Application :
The solar line is suitable for fixed installation in dry and damp rooms or outdoors to connect photovoltaics facilities. They are not
suitable for connecting portable devices for permanent use in water or in the soil. They are considered as short circuit and earth
connection secured.
Suitable for the installation methods reference no. 2, 3A, 4A, 5A, 11, 11A, 12, 13, 14, 15, 16, 21, 22A, 23A, 24A, 25, 31A, 32A,
33A, 34A, 41, 43, 51, 53, 61, 72, 73, 75 given in table 52H of HD 384.5.52 (SEV 1000 cl. 5.2, DIN VDE 0100–520, UNE
20.460–5–52)

General composition of cable:

Technical Data:
Conductor resistance at 20 °C ……………… see table
TüV Nominal voltage line to ground …………. Uo …………………. 600 V AC
……. Nominal voltage line to line ……………….U…………………. 1000 V AC
……. Maximum voltage line to ground ……………………………… 720 V AC
……. Maximum voltage line to line …………….Um……………… 1200 V AC
……. Maximum voltage line to ground ………..Uo………………. 900 V DC
……. Maximum voltage line to line ………………………………….. 1800 V DC
…….. Test voltage AC ……………………………………………………. 6.5 kV
…….. Test voltage DC ……………………………………………………. 15 kV
…….. Lower ambient temperature …………………………………..  -40°C
……. Upper ambient temperature ……………………………………. +90°C
……. Max. conductor temperature ……………………………………. +120°C
Min. bending radius ……………………………………………………….. 4 x D
Maximal tensile strenght ………………….. during installations ………… 50 N/ mm2
                                                                static ……………………………. 15 N/ mm2
Approvals :
(2.5 — 6.0 mm2)
Wires für photovoltaik systems ………….. RADOX Solarkabel ……….. TüV Rheinland 2 Pfg 1169,
……………………………………………………………………………………………… certificate R60024042
The wires are in conformity with :
Vertical flame spread ………………………………. 50 < L ≤ 540 mm ……………….. EN 60332–1–2
Corrosivity of combustion gases …………………pH ≥ 4.3, σ ≤ 10 μS/mm ……… EN 50267–2–2
Amount of halogen acid gas …………………….. HCI + HBr ≤ 0.5% ……………… EN 50267–2–1
Content of fluorine …………………………………… HF ≤ 0.1 % ………………………. EN 60684–2, 45.2
Acid and alkaline resistance …………………….. 168h / 23°C ………………………. EN 60811–2–1, 10
Wheather resistance ……………………………….. 720h ………………………………… EN ISO 4892–2, Meth. A
RoHS Directive ……………………………………….. fulfilled …………………………….. 2002/95/EC
Table :
