Cáp Tín Hiệu Báo Cháy ERSE ERVITAL LIH(St)H FE180/PH120 2X1.5MM2 ORANGE | Chống Nhiễu – Chống Cháy – Giá Tốt Nhất
- Indoors where people are densely populated
- In places where there is electromagnetic intereference
- Instrumentation and control engineering
- Industrial electronics
- For signal transmission
- Indoor communication systems
- In safety and fire alarm systems
- In places where human life and valuable materials and equipment need to be protected
| Conductor | IEC 60228; DIN VDE 0295; EN 60228 Class 5 Stranded Electrolytic Bare Copper |
| Insulation | Cross-linked Ceramic Forming Polymer Compound |
| Colour Code | DIN 47100 |
| Stranding | In layers of optimum pitch |
| Wrapping | Pes Tape + Glass Fibre Tape |
| Screen | Tinned Copper Drain Wire + Al-Pes-Tape |
| Sheath | EN 50290-2-27 HFFR Compound |
| Sheath Colour | RAL 2003 Orange |
| CONDUCTOR RESISTANCE |
INSULATION RESISTANCE (min) |
MUTUAL CAPACITANCE |
OPERATING VOLTAGE |
CURRENT CARRYING CAPACITY |
BENDING RADIUS |
TEST VOLTAGE (50 Hz 1 Min) CORE/CORE |
TEMPERATURE RANGE |
||
| mm² 0,22 0,34 0,50 0,75 1,0 1,5 2,5 |
Ω/km 79 56 39 26 19,5 13,3 7,98 |
MΩxKm 0,22 ve 0,34 mm² = 200 >0,50 mm² = 20 |
nF/km 120 |
0,22mm²/0,34mm² = 250V ≥ 0,50mm² = 300/500V |
mm² 0,22 0,34 0,50 0,75 1,0 1,5 2,5 |
A 2,5 4,5 6,0 13 16 20 25 |
7,5x Cable Ø | 0.22 ve 0.34 mm2 = 1200 V >0.50 mm2 = 2000 V |
-40ºC +70ºC |
| FLAME RETARDANT TEST | FLAME PROPAGATION TEST | SMOKE DENSITY TEST | TEST ON CORROSIVENESS COMBUSTION GASES |
HALOGEN FREE TEST | CIRCUIT INTEGRITY TEST (FE180) |
CIRCUIT INTEGRITY WITH SHOCK TEST (PH120) |
| IEC 60332-1-2 VDE 0482-332-1-2 EN 60332-1-2 BS EN 60332-1-2 |
IEC 60332-3-24 VDE 0482-332-3-24 EN 60332-3-24 BS EN 60332-3-24 |
IEC 61034-2 VDE 0482-1034-2 EN 61034-2 BS EN 61034-2 |
IEC 60754-2 VDE 0482-754-2 EN 60754-2 BS EN 60754-2 |
IEC 60754-1 VDE 0482-754-1 EN 60754-1 BS EN 60754-1 |
IEC 60331-23 | EN 50200 VDE 0482-200 BS EN 50200 |
