SUPERTRONIC® -PURö |
Special cable for drag chains, meter marking |
  |
Technical data
- Special PUR drag chain cables
adapted to DIN VDE 0285-525-2-51 /
DIN EN 50525-2-51 - Very high flexible due to special
construction - Temperature range
flexing -5°C to +70°C
fixed installation -40°C to +70°C - Nominal voltage
350 V - Test voltage
1500 V - Breakdown voltage
min. 3000 V - Insulation resistance
min. 20 MOhm x km - Minimum bending radius
flexing 5x cable Ø
fixed installation 3x cable Ø - Radiation resistance
up to 100×106 cJ/kg (up to 100 Mrad)
Cable structure
- Bare copper conductor, extra fine wire,
acc. to DIN VDE 0295 cl.6, col. 4 and 5
IEC 60228 cl.6 - Oil resistant PVC core insulation TI2,
adapted to DIN VDE 0207-363-3 /
DIN EN 50363-3, for better sliding
abilities - Core identification to DIN 47100,
coloured - Cores stranded in layers with
optimal lay length - Core wrapping with textile tape
- Outer sheath of special full-polyurethane
TMPU to DIN VDE 0207-363-10-2 /
DIN EN 50363-10-2 - Sheath colour: grey (RAL 7001), surface mat
- With meter marking
Properties
- Features
High flexibility at low temperature, high
abrasion resistance, break and cut-resistant,
tear resistant - Resistant to
UV-radiation, Oxygen, Ozone, Hydrolyse, Oil. - Conditional resistant to
Microbes, Hydraulic liquidity,
Alkalis, Lye. - The PUR outer sheath is extremely robust
with high tear, abrasion and oil-resistance. - Adhesion-low
- The materials used during manufacturing
are cadmium-free, contain no silicone
and are free from substances harmful
to the wetting properties of lacquers
Note
- AWG sizes are approximate equivalent
values. The actual cross section is in mm².
Application
Perfect for use with cable trays. This highly flexible PUR control cable is ideal for use wherever frequent high flexing motion is required, e. g. in robotics or all moving parts. The long working life of this cable makes it both efficient and economic. For applications which go beyond standard solutions (for example for composting appliances or high shelf conveyors with extremely high processing speeds etc.) we recommend for our especially developed enquiry sheet for energy guiding systems. Before installation in cable trays please read the instructions. Further technical details see selection table for drag chain cables, see chapter “Technical Information”.
CE = Product conforms with Low-Voltage Directive 2014/35/EU.
