PURö-JZ-HF

high flexible, cable for drag chains, coolant resistant, meter marking

Technical data

• Special polyurethane control cable adapted
  to DIN VDE 0285-525-1/ DIN EN 50525-1
• Temperature range
  flexing -20°C to +80°C
  fixed installation -40°C to +80°C
• Nominal voltage U₀/U 300/500 V
• Test voltage 4000 V
• Breakdown voltage min. 8000 V
• Insulation resistance
  min. 20 MOhm x km
• Minimum bending radius
  flexing 7,5x cable Ø
  fixed installation 4x cable Ø
• Radiation resistance
  up to 100×10⁶ cJ/kg (up to 100 Mrad)

Cable structure

• Bare copper, extra fine wire conductors,
  bunch stranded to DIN VDE 0295 cl.6,
  BS 6360 cl.6 and IEC 60228 cl.6
• Oil resistant PVC core insulation, TI2 in
  adapted to DIN VDE 0207-363-3 /
  DIN EN 50363-3, for better sliding abilities
• Core identification to DIN VDE 0293
  black cores with continuous white
  numbering
• GN-YE conductor, 3 cores and above
  in the outer layer
• Cores stranded in layers with optimal
  selected lay-length
• Core wrapping with fleece
• Outer sheath of speciall full-polyurethane
  TMPU, to DIN VDE 0207-363-10-2 /
  DIN EN 50363-10-2
• Colour grey (RAL 7001)
• with meter marking

Properties

• Suitable for outdoor lying and resistant to
  UV-radiation, oxygen, ozone and hydrolysis.
  Conditionally resistant to microbes
• Adhesion-low
• The materials used in manufacture are
  cadmium-free and contain no silicone
  and free from substances harmful to
  the wetting properties of lacquers

Note

• AWG sizes are approximate equivalent
  values. The actual cross-section is in mm².
• G = with  green-yellow conductor
  x = without  green-yellow conductor (OZ)
• Cross-linked types also available on request.
• screened analogue type:
  PURö-JZ-HF-YCP

Application

PURö-JZ-HF is an extremely robust cable noted for its good tear and abrasion resistance. Due to its good performance with mineral oils and especially in connection with coolants, this cable is well suited for use in the machinery, tool making and steel industries in critical areas. Its high abrasion resistance and good flexing ability make it quick and easy to install and, with its low bending radius, ideal for use with cable trays. For applications which go beyond standard solutions (for example for composting appliances or high shelf conveyors with extremely high processing speeds etc.) we recommend for our especially developed enquiry sheet for energy guiding systems. Before installation in cable trays please read the instructions. Further technical details see selection table for drag chain cables, see lead text.
CE = Product conforms with Low-Voltage Directive 2014/35/EU.
