PURö-JZ-HF-YCP

EMC-preferred type, cable for drag chains, screened, PUR-outer sheath, meter marking

Technical data

• Special polyurethane control cable adapted to
  DIN VDE 0285-525-1 / DIN EN 50525-1
• Temperature range
  flexing -20°C to +80°C
  fixed installation -40°C to +80°C
• Nominal voltage U₀/U 300/500 V
• Test voltage 4000 V
• Breakdown voltage min. 8000 V
• Insulation resistance
  min. 20 MOhm x km
• Minimum bending radius
  flexing 10x cable Ø
  fixed installation 5x cable Ø
• Radiation resistance
  up to 100×10⁶ cJ/kg (up to 100 Mrad)

Cable structure

• Bare copper, extra fine wire conductors,
  bunch stranded to DIN VDE 0295 cl.6,
  col. 4, BS 6360 cl.6 and IEC 60228 cl.6
• Oil resistant PVC core insulation TI2, in
  adapted to DIN VDE 0207-363-3/
  DIN EN 50363-3, for better sliding abilities
• Core identification to DIN VDE 0293
  black cores with continuous white
  numbering
• GN-YE conductor, 3 cores and above
  in the outer layer
• Cores stranded in layers with optimal
  selected lay-length
• Fleece separator
• Oil resistant PVC inner sheath
• One layer of tinned copper wire screening¹⁾,
  approx. 85% coverage
• Outer sheath of special full-polyurethane
  to DIN VDE 0207-363-10-2 /
  DIN EN 50363-10-2
• Colour grey (RAL 7001)
• with meter marking

Properties

• Suitable for outdoor lying and resistant to
  UV-radiation, oxygen, ozone and hydrolysis.
  Conditionally resistant to microbes
• Adhesion-low
• The materials used in manufacture are
  cadmium-free and contain no silicone
  and free from substances harmful to
  the wetting properties of lacquers

Note

• G = with green-yellow conductor
  x = without green-yellow conductor (OZ)
• ¹⁾ Change-over up to construction with
  Cu-screening, tinned, approx. 85% for
  coverage optimisation of the useful
  properties are in preparation
• AWG sizes are approximate equivalent
  values. The actual cross-section is in mm².
• unscreened analogue type:
  PURö-JZ-HF

Application

PURö-JZ-HF-YCP is a highly robust and tare and abrasion resistant cable with excellent resistance properties to mineral oils and cooling fluids, thus making it an ideal choice for installation in most types of industrial machinery as well as in steel works and rolling mills, etc. in fact, wherever you may need a cable to cope with especially critical situations. Easy to install, thanks to its high degree of flexibility. Its high abrasion resistance and good flexing ability make it quick and easy to install and, with its low bending radius, ideal for use with cable trays. This screened cable is ideal for use in data signal transmission free from interferences for measurement and control engineering technology. For applications which go beyond standard solutions (for example for composting appliances or high shelf conveyors with extremely high processing speeds etc.) we recommend for our especially developed enquiry sheet for energy guiding systems. Before installation in cable trays please read the instructions. Further technical details see selection table for drag chain cables, see lead text.
EMC = Electromagnetic compatibillity
To optimize the EMC features we recommend a large round contact of the copper braiding on both ends.
CE = Product conforms with Low-Voltage Directive 2014/35/EU.
