Cáp Điều Khiển Helukabel TOPGEBER 111 PVC | Chính Hãng – Chống Nhiễu Lưới – Feedback Cable – Giá Tốt Nhất

Technical data

• Special core and sheath compound of PVC
• Temperature range
  flexing -5°C to +70°C
  fixed installation -30°C to +80°C
• Nominal voltage
  350 V
• Test voltage
  core/core  2000 V
  core/screen 1000 V
• Insulation resistance
  min. 20 MOhm x km
• Minimum bending radius
  10x cable Ø
• Coupling resistance
  max. 250 Ohm/km

Cable structure

• Bare copper, fine and/or ultra-fine wire
  conductors acc. to DIN VDE 0295 cl.5
  and/or IEC 60228
• Core insulation of PVC
• Part No. 22800 Cu-screen of single
  pairs and PVC sheath
• Core identification see table below
• Single cores or pairs stranded
  in layer with optimal lay length
• Core wrapping with film
• Tinned copper braided screen,
  approx. 85% coverage
• Outer sheath of special PVC
• Sheath colour: grey (RAL 7001)
• With meter marking

Properties

• Extensively oil resistant,
  oil-/chemical resistance
  see “Technical Informations”
• The materials used during manufacturing
  are cadmium-free, contain no silicone
  and are free from substances harmful
  to the wetting properties of lacquers

Tests

• PVC self-extinguishing and flame retardant
  acc. to DIN VDE 0482-332-1-2 /
  DIN EN 60332-1-2 / IEC 60332-1-2

Note

• AWG sizes are approximate equivalent
  values. The actual cross section is in mm².

Application

These feedback cables are used in machinery and control construction as well as in plant engineering as these enable an excellent transmission of data and signals. Additional cores for the power supply to individual components are available.
EMC = Electromagnetic compatibility
To optimize the EMC features we recommend a large round contact of the copper braiding on both ends.
CE = Product conforms with Low-Voltage Directive 2014/35/EU.
