THERMFLEX^® 180 EWKF

Silicone multicore cable, halogen-free, meter marking

Technical data

• adapted to
  DIN VDE 0285-525-2-83 /
  DIN EN 50525-2-83
• Temperature range
  flexing -25°C to +180°C
  fixed installation -60°C to +180°C
• Nominal voltage  U₀/U 300/500 V
• Test voltage  2000 V
• Insulation resistance
  min. 200 MOhm x km
• Minimum bending radius
  flexing 7,5x cable Ø
  fixed installation 4x cable Ø
• Radiation resistance
  up to 20×10⁶ cJ/kg (up to 20 Mrad)

Tests

• Insulation integrity testet acc. to
  DIN VDE 0472-814 / IEC 60331
• Halogen free acc. to
  DIN VDE 0482-267 /
  DIN EN 50267-2-1 / IEC 60754-1
• Behaviour in fire
  no flame propagation acc. to
  DIN VDE 0482-332-1-2 /
  DIN EN 60332-1-2 / IEC 60332-1-2
• Corrosiveness of combustion gases
  acc. to DIN VDE 0482-267 /
  DIN EN 50267-2-2 / IEC 60754-2

Cable structure

• Tinned copper conductor, fine wire
  acc. to DIN VDE 0295 cl.5 /
  BS 6360 cl.5 / IEC 60228 cl.5
• Core insulation of special silicone
  compound type EI2 to
  DIN VDE 0207-363-1 / DIN EN 50363-1
• Core identification to DIN VDE 0293-308
  – up to 5 cores coloured
  – from 6 cores, black with continuous
  white numbering
• GN-YE conductor, 3 cores and above
  in the outer layer
• Cores stranded in layers with
  optimal lay length
• Outer sheath of special silicone
  compound type 2GM1 to
  DIN VDE 0207-363-2-1/DIN EN 50363-2-1
• Sheath colour: black (RAL 9005)
• With meter marking

Properties

• Low smoke density
• Due to the special abrasive and notch
  resistance outer sheath, these cables are
  suitable for heavy loading of mechanical
  stresses than the usual standard silicone
  cables
• Advantages
  hardly changes of dielectric strength
  and the insulation resistance also at
  high temperatures, high ignition or
  flash point, leave in case of fire an
  insulating layer of SiO₂ thereby
  ensuring a longer functional integrity
• Resistant to
  high molecular oils, fats from vegetables
  and animals, alcohols, plasticizers and
  clophenes, diluted acids, lyes and salt
  dissolution, oxidation substances,
  atmospheric influences, lake water,
  oxygen, ozone

Note

• G = with GN-YE conductor
  x = without GN-YE conductor
• AWG sizes are approximate equivalent
  values. The actual cross section is in mm².
• EWKF = Improved values to
  E=tearing resistance,
  W=breaking strength propagation,
  K=notch strength, F=flexibility
• Screened analogue type:
  THERMFLEX^® 180 EWKF-C

Application

These cables are ideal for use everywhere, where they are exposed to high mechanical stresses, as well as wire insulation are subjected to high temperatures. For use in dry, damp and wet rooms, as well outdoor. Silicone cables are halogen free and are suitable for use in air conditioning and heating, for lighting, for the wiring of ovens, saunas and solariums, foundries, steel, cement and ceramic works and in the heating and cooling equipment.
FRNC = Flame Retardant Non Corrosive
All silicone cables are available also in FRNC versions. The sheath designed with special-compound conform flame test method C to DIN VDE 0472-804 and IEC 60332-3 as well as HD 405.3. This special compound is self-extinguishing. Because of that these cables can be installed as security cable with functionality as for example in communal buildings, power stations, hotels, airports etc.
CE = Product conforms with Low-Voltage Directive 2014/35/EU.
