HELUSPREADER YSLTÖ-J

Spreader cable for vertical basket enterprise

Technical data

• Special cable adapted to
  DIN VDE 0250
• Temperature range
  flexing -20°C to +60°C
  fixed installation -20°C to +60°C
• Max. operating temperature
  at conductor +90°C
• Max. short circuit temperature
  at conductor +150°C
• Nominal voltage
  U₀/U 300/500 V
• Max. tensile load
  2000 N
• Minimum bending radius
  15x cable Ø
• Current carrying capacity
  to DIN VDE 0298-4

Cable structure

• Bare copper conductor, to
  DIN VDE 0295 cl.5 or cl.6, fine wire
  or extra fine wire, BS 6360 cl.5 or cl.6,
  IEC 60228 cl.5 or cl.6
• Core insulation of special EPR
• Core identification to DIN VDE 0293
  black cores with continuous white
  numbering
• GN-YE conductor
• Cores laid-up in lay of length,
  stranding with optimal length
  of twists around a Kevlar element
• Outer sheath of special polychloropren
• Sheath colour: black (RAL 9005)

Properties

• Weather resistant
• UV-resistant
• High abrasion resistance

Note

• G = with GN-YE conductor
  Delivery on request:
• also as -K model, temperature range
  -40°C to +80°C
• further dimensions and special designs
• AWG sizes are approximate equivalent
  values. The actual cross section is in mm²

Application

As Spreader cable with high mechanical stresses in vertical basket operation in dry, moist, wet environment and in open air. Please note that at the installation the cable must be placed counterwise and free of twist into the basket.
CE = Product conforms with Low-Voltage Directive 2014/35/EU.
