(N)SHTÖU-V

Trailing cable

Technical data

• Special trailing cable adapted to
  DIN VDE 0250 part 814
• Temperature range
  flexing -25°C to +80°C
• Max. temperature at the conductor
  during operation  +90°C
  in case of short circuit  +250°C
• Nominal voltage
  U₀/U 0,6/1 kV
• Max. permissible operating voltage
  Max. permissible operating voltage
  – 3-Phase and single phase
  operation 700/1200 V
  – DC operation 900/1800 V
• Test voltage
  4 kV
• Minimum bending radius
  7,5x cable Ø

Cable structure

• Tinned copper conductor, to
  DIN VDE 0295 cl.5, fine wire,
  BS 6360 cl.5, IEC 60228 cl.5
• Core insulation of special rubber
  compound type 3GI3 to
  DIN VDE 207-20
• Core identification to DIN VDE 0293-308
• GN-YE conductor
• Cores stranded
• Depending on dimension/structure
  with Kevlar fillers
• Inner sheathof special rubber
  compound type 5GM5 to
  DIN VDE 0207-21
• Torsion protection between
  inner and outer sheath
• Outer sheath of special rubber
  compound type 5GM5 to
  DIN VDE 0207-21
• Sheath colour: yellow

Properties

• Designed and developed for
  vertical reeling applications.
• Resistant against
  acids, fats, gazoline,
  solvents and chemicals.

Tests

• Behaviour in fire
  acc. to DIN VDE 0482-332-1-2 /
  DIN EN 60332-2-1 / IEC 60332-1-2
• Oil resistant acc. to
  DIN VDE 0473-811-404/DIN EN 60811-404

Note

• Permitted running speed up 180 m/min
• AWG sizes are approximate equivalent
  values. The actual cross section is in mm².

Application

For vertical drum operation under extreme mechanical stress and on moving cable carrieres. Used as a rugged feeder to construction machines, conveyor, transport and crane systems in dry, damp, wet environments and outdoors. For applications which go beyond standard solutions we recommend that you fill out our especially developed questionnaire for reeling cables. Please read the installation instructions, see chapter “Technical Informations”.
CE = Product conforms with Low-Voltage Directive 2014/35/EU.

Downloads

Data sheet

Power supply Cable

Control Cable (Kevlar fillers)
