Download PDF : PUR5525WH-UY
PUR5525WH-UY
Copper cable, category 5e UTP,riser (CMR), 25-pair, conductors are 24 AWG construction with HDPE insulation, twisted in pairs and placed in a flame-retardant PVC jacket, white.
| AWG Size | 24 |
| Length (ft.) | 1000 |
| Length (m) | 305 |
| Nominal Diameter (In.) | 0.500 |
| Nominal Diameter (mm) | 12.7 |
| Jacket Material | Flame-retardant PVC (CMR) |
| No. of Pairs | 25 |
| Packaging Type | Reel |
| CE Compliant | No |
| Application | Ethernet 10BASE-T, 100BASE-T (Fast Ethernet), 1000BASE-T (Gigabit Ethernet), 155 Mb/s ATM, Token Ring 4/16, Voice and multimedia systems, High-density voice and data applications for backbone and cross connect installations |
| Cable Type | U/UTP |
| Flammability Rating | Riser – UL 1666 |
| Part Features | Descending length cable markings, Third party tested and Tested beyond standards |
| Weight (Kg) | 60/395m |
| Weight (lbs) | 132/1000 ft. |
| RoHS Compliancy Status | Compliant |
