H07V-K / (H)07V-K

PVC-Single Cores, fine wire stranded

Logo Image Logo Image Logo Image

Technical data

  • PVC single cores to
    DIN VDE 0285-525-2-31/
    DIN EN 50525-2-31 and IEC 60227-3
  • Temperature range
    flexing -5°C to +70°C
    fixed installation -30°C to +80°C
  • Nominal voltage
    U0/U 450/750 V
  • Test voltage
    2500 V
  • Insulation resistance
    min. 10 MOhm x km
  • Minimum bending radius
    fixed installation
    core Ø ≤ 8 mm: 4x core Ø
    core Ø > 8-1 2 mm: 5x core Ø
    core Ø > 12 mm: 6x core Ø
  • Radiation resistance
    up to 80×106 cJ/kg (up to 80 Mrad)

Cable structure

  • Bare copper conductor, to
    DIN VDE 0295 cl.5, fine wire,
    BS 6360 cl.5, IEC 60228 cl.5
  • Core insulation of PVC
    compound type TI1 to
    DIN VDE 0207-363-3 / DIN EN 50363-3
    and IEC 60227-3
  • Core identification: see table below

Properties

  • The materials used during manufacturing
    are cadmium-free, contain no silicone
    and are free from substances harmful
    to the wetting properties of lacquers

Tests

  • PVC self-extinguishing and flame retardant
    acc. to DIN VDE 0482-332-1-2 /
    DIN EN 60332-1-2 / IEC 60332-1-2

Note

  • The following colours are recommended
    (only single colour): black, white, blue, grey,
    brown, red, orange, turquoise, violet and
    pink. Two-coloured combinations are not
    allowed, with exceptions of green-yellow.
  • Colours yellow, green, transparent only in
    (H)07V-K available.
  • Two-coloured combination is only
    permitted for (H)07V-K.

Application

These single cores are suitable for laying in tubes, under and surface mounting of plasters and also in closed installation conduits. These are not allowed to install for direct laying on cable trays, channels or tanks. These types are permitted for the inner wiring of equipment, distributor and switchboards and also for protective laying to the lightings with a nominal voltage up to 1000 V alternating current or up to 750 V direct current against earth.
CE = Product conforms with Low-Voltage Directive 2014/35/EU.

Downloads

Data sheet

H07V-K, (H)07V-K

Cross-
sec.

mm²

Outer Ø

min. – max.

mm

Cop.
weight

kg / km

black Green-yellow blue brown red white grey violet yellow pink green TRANS dark blue OR Two-colour u-blue
approx. RAL 9005 5015 8003 3000 9003 7001 4005 1021 3015 6018 5010 2003

/opc/workarea/suppliers/STD/documents/Spule.jpg
Packing Spool (with various capacity)
H07V-K spool
Part no. 26690 26691 26692 26693 26694 26695 26696 26697 26698 26699 26700 26701 26702 26703 26705 26399
1,5 2,8 – 3,4 14,4
Part no. 26706 26707 26708 26709 26710 26711 26712 26713 26714 26715 26716 26717 26718 26719 26721 26400
2,5 3,4 – 4,1 24,0
Part no. 26722 26723 26724 26725 26726 26727 26728 26729 26730 26731 26732 26733 26734 26735 26737 26401
4 3,9 – 4,8 38,0
Part no. 26738 26739 26740 26741 26742 26743 26744 26745 26746 26747 26748 26749 26750 26751 26753 26402
6 4,4 – 5,3 58,0

H07V-K, (H)07V-K

Cross-
sec.

mm²

Outer Ø

min. – max.

mm

Cop.
weight

kg / km

black Green-yellow blue brown red white grey violet yellow pink green TRANS dark blue OR Two-colour u-blue
approx. RAL 9005 5015 8003 3000 9003 7001 4005 1021 3015 6018 5010 2003

/opc/workarea/suppliers/STD/documents/Fass.jpg
Packing Barrel (with various capacity)
H07V-K barrel
Part no. 26755 26756 26757 26758 26759 26760 26761 26762 26763 26764 26765 26766 26767 26768 26770 26403
1,5 2,8 – 3,4 14,4
Part no. 26771 26772 26773 26774 26775 26776 26777 26778 26779 26780 26781 26782 26783 26784 26786 26404
2,5 3,4 – 4,1 24,0
Part no. 26787 26788 26789 26790 26791 26792 26793 26794 26795 26796 26797 26798 26799 26800 26802 26819
4 3,9 – 4,8 38,0
Part no. 26803 26804 26805 26806 26807 26808 26809 26810 26811 26812 26813 26814 26815 26816 26818 26820
6 4,4 – 5,3 58,0

H07V-K, (H)07V-K

Cross-
sec.

mm²

Outer Ø

min. – max.

mm

Cop.
weight

kg / km

black Green-yellow blue brown red white grey violet yellow pink green TRANS dark blue OR Two-colour u-blue
approx. RAL 9005 5015 8003 3000 9003 7001 4005 1021 3015 6018 5010 2003 5002

/opc/workarea/suppliers/STD/documents/Ring.jpg
Packing Coil in cardboard (100m)
H07V-K coil
Part no. 29129 29130 29131 29132 29133 29134 29135 29136 29137 29138 29139 29140 29141 29142 29144 26395
1,5 2,8 – 3,4 14,4
Part no. 29145 29146 29147 29148 29149 29150 29151 29152 29153 29154 29155 29156 29157 29158 29160 26396
2,5 3,4 – 4,1 24,0
Part no. 29161 29162 29163 29164 29165 29166 29167 29168 29169 29170 29171 29172 29173 29174 29176 26397
4 3,9 – 4,8 38,0
Part no. 29177 29178 29179 29180 29181 29182 29183 29184 29185 29186 29187 29188 29189 29190 29192 26398
6 4,4 – 5,3 58,0

H07V-K, (H)07V-K

Cross-
sec.

mm²

Outer Ø

min. – max.

mm

Cop.
weight

kg / km

black Green-yellow blue brown red white grey violet yellow pink green TRANS dark blue OR Two-colour u-blue
approx. RAL 9005 5015 8003 3000 9003 7001 4005 1021 3015 6018 5010 2003

/opc/workarea/suppliers/STD/documents/Rolle.jpg
Packing Coil in foil (100m)
H07V-K coil
Part no. 26060 26061 26062 26063 26064 26065 26066 26067 26068 26069 26092 26099 26108 26109 26111 26821
1,5 2,8 – 3,4 14,4
Part no. 26112 26113 26114 26115 26116 26117 26118 26119 29855 29856 29857 29858 29859 29890 29892 26822
2,5 3,4 – 4,1 24,0
Part no. 29893 29894 29895 29896 29897 29898 29899 29905 29906 29907 29908 29909 29910 29911 29913 26823
4 3,9 – 4,8 38,0
Part no. 29914 29915 29916 29917 29918 29919 29921 29922 29923 29924 29925 29926 29927 29928 29933 26824
6 4,4 – 5,3 58,0
Part no. 29193 29194 29195 29196 29197 29198 29199 29200 29201 29202 29203 29204 29205 29206 29208
10 5,7 – 6,8 96,0
Part no. 29209 29210 29211 29212 29213 29214 29215 29216 29217 29218 29219 29220 29221 29222 29224
16 6,7 – 8,1 154,0
Part no. 29225 29226 29227 29228 29229 29230 29231 29232 29233 29234 29235 29236 29237 29238 29240
25 8,4 – 10,2 240,0
Part no. 29241 29242 29243 29244 29245 29246 29247 29248 29249 29250 29251 29252 29253 29254 29256
35 9,7 – 11,7 336,0
Part no. 29257 29258 29259 29260 29261 29262 29263 29264 29265 29266 29267 29268 29269 29270 29272
50 11,5 – 13,9 480,0
Part no. 29273 29274 29275 29276 29277 29278 29279 29280 29281 29282 29283 29284 29285 29286 29288
70 13,2 – 16,0 672,0
Part no. 29289 29290 29291 29292 29293 29294 29295 29296 29297 29298 29299 29300 29301 29302 29304
95 15,1 – 18,2 912,0
Part no. 29418 29419 29420 29421 29422 29423 29424 29425 29426 29427 29428 29429 29430 29431 29433
120 16,7 – 20,2 1152,0
Part no. 29434 29435 29436 29437 29438 29439 29440 29441 29442 29443 29444 29445 29446 29447 29449
150 18,6 – 22,5 1440,0
Part no. 29494 29495 29496 29497 29498 29499 29590 29591 29592 29593 29594 29595 29596 29597 29599
185 20,6 – 24,9 1776,0
Part no. 29813 29814 29815 29816 29817 29818 29819 29840 29841 29842 29843 29844 29845 29846 29848
240 23,5 – 28,4 2304,0
Cross-
sec.

mm²

Outer Ø

min. – max.

mm

Cop.
weight

kg / km

black Green-yellow blue brown red white grey violet yellow pink green TRANS dark blue OR Two-colour u-blue
approx. RAL 9005 5015 8003 3000 9003 7001 4005 1021 3015 6018 5010 2003 2003

/opc/workarea/suppliers/STD/documents/Spule2.jpg
Packing Drum
H07V-K drum
Part no. 26825 26826 26827 26828 26829 26830 26831 26832 26833 26834 26835 26836 26837 26838 26840
10 5,7 – 6,8 96,0
Part no. 26841 26842 26843 26844 26845 26846 26847 26848 26849 26850 26851 26852 26853 26854 26856
16 6,7 – 8,1 154,0
Part no. 26857 26858 26859 26860 26861 26862 26863 26864 26865 26866 26867 26868 26869 26870 26872
25 8,4 – 10,2 240,0
Part no. 26873 26874 26875 26876 26877 26878 26879 26880 26881 26882 26883 26884 26885 26886 26888
35 9,7 – 11,7 336,0
Part no. 26889 26890 26891 26892 26893 26894 26895 26896 26897 26898 26899 26900 26901 26902 26904
50 11,5 – 13,9 480,0
Part no. 26905 26906 26907 26908 26909 26910 26911 26912 26913 26914 26915 26916 26917 26918 26920
70 13,2 – 16,0 672,0
Part no. 26921 26922 26923 26924 26925 26926 26927 26928 26929 26930 26931 26932 26933 26934 26936
95 15,1 – 18,2 912,0
Part no. 29305 29306 29307 29308 29309 29310 29311 29312 29313 29314 29315 29316 29317 29318 29320
120 16,7 – 20,2 1152,0
Part no. 29321 29322 29323 29324 29325 29326 29327 29328 29329 29330 29331 29332 29333 29334 29336
150 18,6 – 22,5 1440,0
Part no. 29337 29338 29339 29340 29341 29342 29343 29344 29345 29346 29347 29348 29349 29350 29352
185 20,6 – 24,9 1776,0
Part no. 29353 29354 29355 29356 29357 29358 29359 29360 29361 29362 29363 29364 29365 29366 29368
240 23,5 – 28,4 2304,0
