Download PDF : PUZ5504BU-CEG
PUZ5504BU-CEG
High performance copper cable, category 5e U/UTP, low smoke zero halogen (LSZH), 4-pair, conductors are 24 AWG construction with HDPE insulation, twisted in pairs and all four pairs are covered by a LSZH jacket, blue.
| AWG Size | 24 |
| Length (ft.) | 1000 |
| Length (m) | 305 |
| Nominal Diameter (In.) | 0.205 |
| Nominal Diameter (mm) | 5.2 |
| Jacket Material | LSZH – Low smoke zero halogen |
| No. of Pairs | 4 |
| Packaging Type | Reel |
| CE Compliant | No |
| Application | Ethernet 10BASE-T, 100BASE-T (Fast Ethernet), 1000BASE-T (Gigabit Ethernet), 155 Mb/s ATM, 622 Mb/s ATM, Token ring 4/16 |
| Cable Type | U/UTP |
| Flammability Rating | LSZH – IEC 60332-3-25 (-3d), IEC 60754-1 and -2, IEC 61034-2, |
| Nominal Cable O.D. (In.) | 0.205 |
| Nominal Cable O.D. (mm) | 5.2 |
| Part Features | Third party tested, Tested beyond the standards and Packaged on a reel |
| Weight (Kg) | 10/305m |
| Weight (lbs) | 22/1000 ft. |
| RoHS Compliancy Status | Compliant |
