Cáp Quang NECERO GYXTW Single-mode 9/125μm ( Đơn Mode ) 2, 4, 6, 8, 12, 24, 48 FO / Core / Lõi

Cáp Quang NECERO GYXTW Multi-mode OM1 62.5/125μm ( Đa Mode ) 2, 4, 6, 8, 12, 24, 48 FO / Core / Lõi

Cáp Quang NECERO GYXTW Multi-mode OM2 50/125μm ( Đa Mode ) 2, 4, 6, 8, 12, 24, 48 FO / Core / Lõi

Cáp Quang NECERO GYXTW Multi-mode OM3 50/125μm ( Đa Mode ) 2, 4, 6, 8, 12, 24, 48 FO / Core / Lõi

Cáp Quang NECERO GYXTW Multi-mode OM4 50/125μm ( Đa Mode ) 2, 4, 6, 8, 12, 24, 48 FO / Core / Lõi

·Description

The fibers, 250μm, are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. The tube is wrapped with a layer of PSP longitudinally. Between the PSP and the loose tube water-blocking material is applied to keep the cable compact and watertight. Two parallel steel wires are placed at the two sides of the steel tape. The cable is completed with a polyethylene (PE) sheath.

·Characteristics

· Good mechanical and temperature performance

· High strength loose tube that is hydrolysis resistant

· Special tube filling compound ensure a critical protection of fiber

· Crush resistance and flexibility

· PSP enhancing moisture-proof

· Two parallel steel wires ensure tensile strength

· Small diameter, light weight and friendly installation

· Long delivery length

·Standards

GYXTW cable complies with Standard YD/T 769-2003.

·Optical Characteristics

G.652 G.655 50/125μm 62.5/125μm
Attenuation

(+20℃)

@850nm ≤3.0 dB/km ≤3.0 dB/km
@1300nm ≤1.0 dB/km ≤1.0 dB/km
@1310nm ≤0.36 dB/km ≤0.40 dB/km
@1550nm ≤0.22 dB/km ≤0.23dB/km
Bandwidth (Class A) @850nm ≥500 MHz·km ≥200 MHz·km
@1300nm ≥1000 MHz·km ≥600 MHz·km
Numerical Aperture 0.200±0.015NA 0.275±0.015NA
Cable Cut-off Wavelength λcc ≤1260nm ≤1480nm
·Technical Parameters
Cable Type Fiber Count Cable Diameter

mm

Cable Weight kg/km Tensile Strength



Long/Short Term N

Crush Resistance



Long/Short Term

N/100mm

Bending Radius



Static
/Dynamic

mm

GYXS/GYXTW-2~12 2~12 10.0 105 600/1500 300/1000 10D/20D
GYXS/GYXTW-2~12 2~12 10.6 124 1000/3000 1000/3000 10D/20D
GYXS/GYXTW-14~24 14~24 12.5 149 1000/3000 1000/3000 10D/20D
GYXS/GYXTW-26~36 26~36 14.0 190 1000/3000 1000/3000 10D/20D
GYXS/GYXTW-38~48 38~48 15.0 216 1000/3000 1000/3000 10D/20D
Storage/Operating Temperature : -40℃ to + 70℃
