IUC6C04ABL-CEG
Copper cable, category 6 U/UTP, industrial, 4-pair, conductors are 24/7 AWG construction with HDPE insulation, twisted in pairs, surrounded by a PVC jacket.
| Color | Black |
| AWG Size | 24 |
| Length (ft.) | 1000 |
| Length (m) | 305 |
| Nominal Diameter (In.) | 0.268 |
| Nominal Diameter (mm) | 6.8 |
| Jacket Material | Flame retardant PVC, oil, UV, and abrasion resistant |
| No. of Pairs | 4 |
| Packaging Type | Reel |
| CE Compliant | No |
| Application | 10BASE-T (Ethernet), 100BASE-T (Fast Ethernet), 1000BASE-T (Gigabit Ethernet), Industrial Ethernet, Ethernet/IP, Downlinks from control panel to the machine area, Uplinks featuring gigabit data transmission, from the control panel to the consolidation point |
| Cable Type | U/UTP |
| Flammability Rating | CM (UL1685) |
| Insulation Diameter (In.) | 0.038 – 0.042 |
| Insulation Diameter (mm) | 0.97 – 1.07 |
| Part Features | Third party tested, Descending length cable markings, Packaged on a reel |
| Performance Level | 6 |
| Weight (Kg) | 26/305m |
| Weight (lbs) | 58/1000ft. |
| RoHS Compliancy Status | Compliant |
