Cáp LAPP KABEL UNITRONIC® ST 2464

Data communication systems
Low frequency data transmission cables
Metal foil screened pairs

LAPPKABEL UNITRONIC® ST 2464

• product information ( PDF )

■ Application range

• Suitable for use in instrumentation, industrial automation and process control application

• For use in dry and damp environment

• UV-resistant and impervious to moisture penetration

■ Product features

• 100% screen coverage, offers optimum protection against external interference at medium and high frequencies

• Ƕ Flame retardant in acc. to IEC 60332-1-2

■ Approvals (Norm references)

■ Design

• Multi-wire strands of bare copper wires

• SR-PVC core insulation

• Cores twisted together

• Overall screen of aluminium foil

• PVC outer sheath

• Bare copper drain wire

• Colour: black (RAL 9005)

Technical data

Core identification code
1-Pair: black/white
2-Pair: black/white, black/red
Mutual capacitance
C/C: approx. 200 pF/m
C/S: approx. 370 pF/m
Peak operating voltage
300 V (not for power applications)
Specific insulation resistance
> 2 GOhm x km
Inductivity
approx. 0.62 mH/km
Minimum bending radius
10 x cable diameter
Test voltage
1000 V
Temperature range
-30°C to +80°C
Characteristic impedance
100 Ohm
